FRAM CH10515 Pass Car Cartridge Oil Filter

★★★★★ (0) Write a Review
CH10515 by FRAM - Pass Car Cartridge Oil Filter
FRAM
Tap to view 5 more

No Stock Available

We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.

We may have similar parts for sale. Search Alternatives >

FRAM CH10515 Part Description

Manufacturer

FRAM

Product Description

FRAM, CH10515, Oil Filter

Features & Benefits

  • Proven protection for up to 10,000 miles (16,000 kilometers)
  • Engineered for use with synthetic or conventional motor oils
  • Filter media is a blend of fiber and resin that captures 95% of the dirt particles
  • The perfect balance of dirt-trapping efficiency and dirt-holding capacity
  • Includes gaskets and O-rings manufactured to endure the high pressures and high temperatures in today’s engines
  • Includes gaskets and O-rings manufactured to endure the high pressures and high temperatures in today's engines

Cartridge Oil Filter

FRAM CH10515 Specifications

Product Attributes

Filter Media Material Cellulose/Synthetic Blend
Height 4.213 IN
Grade Type Regular
Filter Type Cartridge
Non Slip Grip No
Anti-Drain Back Valve No
Bypass Relief Valve No
Grade Advanced
Housing Color NA
Inside Diameter Bottom 1.004 IN
Meets Or Exceeds Original Equipment Manufacturer Specifications Yes
New Or Remanufactured New
O-ring (1) Inside Diameter 0.441 IN
O-ring (1) Outside Diameter 0.539 IN
O-ring (1) Thickness 0.098 IN
O-ring (2) Inside Diameter 0.315 IN
O-ring (2) Outside Diameter 0.453 IN
O-ring (2) Thickness 0.138 IN
O-ring Inside Diameter 2.913 IN
O-ring Outside Diameter 3.051 IN
O-ring Thickness 0.138 IN
O-Rings Included Yes
Outer Diameter Bottom 2.559 in
Outer Diameter Top 2.559 in
Replacable Filter Yes
Reusable No
Top Inside Diameter 1.004 in
Torque Nut No
Washable No
Washer Inside Diameter 0.551 IN
Washer Outside Diameter 0.787 IN
Washer Thickness 0.079 IN
Bottom Inside Diameter 1.004 IN
Outside Diameter Top 2.559 in
Replaceable Filter Yes

Additional Information

Country of Origin (Primary) CN
Harmonized Tariff Code (HTS) 8421230000
Warranty Special See Rep
Warranty Special UOM SR
Warranty Time 30
Warranty Time UOM DA
UPC 00009100539021
UNSPSC 15121501

FRAM CH10515 Cross References

BrandPart Number
BALDWINP7364
BECK/ARNLEY041-0825, 041-0846, 041-0847
Bosch72257WS, 3848
CARQUEST84029, 84042, 84250
CHAMPP982
CarquestR84250, R84029
Carquest Premium Filters84029, 84042, 84250
Casite FiltersCF642
ChampP994
ChampionCOC10515
Champion FiltersCOC10515
DENSO150-3078
Defense FiltersDL10515
ECOGARDX5848
ECOGUARDX5848
EXXON/MOBIL OILM1C255, M1C255A
FRAMM1C-255A, M1C-255
FRAM DriveFD10515
FRAM ForceFF10515
FRAM TitaniumFS10515
FRAM Tough GuardTG10515
FRAM Ultra SyntheticXG10515
FVPG7029
Factory Motor PartsG7029
ForecastOF69
GMB699-1017
HASTINGSLF642
HastingsLF642F, LF654
Hyundai26300-3C250, 26320-3C250, 26320-3C300, 26320-3C30A, 26320-3C700, 26320-3F100
K&NHP-7029, PS-7029
Kia26320-3C250, 26320-3C300, 26320-3C30A, 26320-3F100
LUBER-FINERP982, P994
MAHLEOX 351D ECO, OX351DECO, OX 351D, OX351D
MOBIL OILM1C255, M1C255A
MicroGardMGL10515, MGL57029, MGL57250
MicroGard SelectMSL57029
Mighty Distributing SystemMX982
Mobil 1M1C-255, M1C-255A
NAPA7029, 7042, 7250
PUROLATORTL25848, PL25848
Parts Master67029, 67250
PennzoilHPZ-174, PZ174
PerformaxS10515XL, PO-174
Premium GuardPG5848, PG5848A
PromotivePH5848
PureZone8-57250
PurolatorL25848
Purolator PureONEPL25848
PurolatorONEPL25848
Quaker StateQS174
STP FiltersS10515, S10515XL
Service ChampCF5848
ValvolineVO-99, VO99
WIX FILTERS57029, 57250
WarnerWP982
Warner FiltersWP982
Wix57042, 57250, 57029

FRAM CH10515 Fits Vehicles

  • Suzuki Aerio (2002)
  • Kia Sorento (2008-2009)
  • Kia K900 (2015-2017)
  • Hyundai Equus (2011-2016)
  • Hyundai Genesis Coupe (2010-2016)
  • Hyundai Azera (2009-2011)
  • Hyundai Santa Fe (2009)
  • Kia Borrego (2009-2011)
  • Kia Amanti (2009)
  • Hyundai Genesis (2009-2014)
  • Kia Sedona (2008-2010)
  • Hyundai Sonata (2009-2010)
  • Hyundai Veracruz (2007-2012)
