FRAM CH10530 Part Description
Manufacturer
Product Description
FRAM, CH10530, Oil Filter
Features & Benefits
- Proven protection for up to 10,000 miles (16,000 kilometers)
- Engineered for use with synthetic or conventional motor oils
- Filter media is a blend of fiber and resin that captures 95% of the dirt particles
- The perfect balance of dirt-trapping efficiency and dirt-holding capacity
- Includes gaskets and O-rings manufactured to endure the high pressures and high temperatures in today’s engines
- Includes gaskets and O-rings manufactured to endure the high pressures and high temperatures in today's engines
Cartridge Oil Filter
FRAM CH10530 Specifications
Product Attributes
| Filter Media Material | Cellulose/Synthetic Blend |
| Height | 4.074 IN |
| Grade Type | Regular |
| Filter Type | Cartridge |
| Non Slip Grip | No |
| Anti-Drain Back Valve | No |
| Bypass Relief Valve | No |
| Grade | Advanced |
| Housing Color | NA |
| Inside Diameter Bottom | 1.299 IN |
| Meets Or Exceeds Original Equipment Manufacturer Specifications | Yes |
| New Or Remanufactured | New |
| O-ring (1) Inside Diameter | 0.433 IN |
| O-ring (1) Outside Diameter | 0.531 IN |
| O-ring (1) Thickness | 0.098 IN |
| O-ring Inside Diameter | 3.307 IN |
| O-ring Outside Diameter | 3.444 IN |
| O-ring Thickness | 0.137 IN |
| O-Rings Included | Yes |
| Outer Diameter Bottom | 2.874 in |
| Outer Diameter Top | 2.874 in |
| Replacable Filter | Yes |
| Reusable | No |
| Top Inside Diameter | 0.551 in |
| Torque Nut | No |
| Washable | No |
| Washer Inside Diameter | 0.720 IN |
| Washer Outside Diameter | 0.858 IN |
| Washer Thickness | 0.059 IN |
| Bottom Inside Diameter | 1.299 IN |
| Outside Diameter Top | 2.874 in |
| Replaceable Filter | Yes |
Additional Information
| Country of Origin (Primary) | KR |
| Harmonized Tariff Code (HTS) | 8421230000 |
| Warranty Special | See Rep |
| Warranty Special UOM | SR |
| Warranty Time | 30 |
| Warranty Time UOM | DA |
| UPC | 00009100539496 |
| UNSPSC | 15121501 |
FRAM CH10530 Cross References
| Brand | Part Number |
|---|---|
| BALDWIN | P40100 |
| BECK/ARNLEY | 041-8182 |
| BMW | 11 42 7 521 008, 11 42 7 542 021, 11 42 7 527 957 |
| CARQUEST | 84171 |
| CHAMP | P962 |
| CITGO | P962 |
| Carquest | 84175 |
| Citgo Petroleum | P962 |
| D67 | LUBER-FINER |
| ECOGUARD | X5564 |
| FVP | G7171B |
| Factory Motor Parts | G7171B |
| GK Industries | EF25564 |
| HENGST | E203H04 |
| Hastings | LF646 |
| Hengst | E203H04 D67 |
| LUBER-FINER | P962 |
| MAHLE | OX636DECO, OX 636D ECO, OX 636D |
| Mann-Filter | HU823X |
| MicroGard | MGL57175 |
| MicroGard Select | MSL57175 |
| Mobil | P962 |
| NAPA | 7171, 7175 |
| Original Engine Management | OF53 |
| PARTS PLUS | P962EX |
| PREMIUM GUARD | PG5564EX |
| Parts Master | 67175 |
| Premium Guard | PG5564 |
| Premium Guard Extended Life | PG5564EX |
| Purolator | L25564 |
| STP | P962, S10530 |
| STP Filters | P962, S10530, S1053XL |
| Service Champ | CF5564 |
| Valvoline | VO-112 |
| WIX FILTERS | 57175 |
| Warner | WP962 |
| Warner Filters | WP962 |
| Wix | 57171, 57175 |
FRAM CH10530 Fits Vehicles
- Suzuki Aerio (2002)
- BMW 760i (2005-2006)
- BMW X5 (2007-2010)
- BMW 750i (2006-2008)
- BMW 750Li (2006-2008)
- BMW 550i (2006-2010)
- BMW 650i (2006-2010)
- Rolls-Royce Phantom (2004-2013)
- BMW 760Li (2003, 2005-2008, 2010)
