(888) 312-8812 Login SignupFLEETGUARD LF767 Engine Oil Filter - 4.58 in. Height, 3.01 in. (Largest OD), GMC 25010324
Tap to view 1 more
SHIPS MONDAY
$2249
Limited availability at this price!
In Stock
Get it by Thursday, Jan 8
FLEETGUARD LF767 Part Description
FLEETGUARD LF767 Specifications
Product Attributes
| Height | 4.58 in. (116.33 mm) |
| Micron Rating | 95 percent at 30 Microns |
| Gasket Inside Diameter | 2.46 in. (62.48) |
| Gasket Outside Diameter | 2.83 in. (71.88) |
| Notes | Spin-On |
| Outside Diameter (Largest) | 3.01 in. (76.45 mm) |
| Seam Outside Diameter | 3.06 in. (77.72) |
| Standpipe | NO |
| Thread Size | 13/16-16 UNS-2B |
| Largest Od | 76.45 mm |
| Overall Height | 4.58 in |
Additional Information
| Warranty Distance | 100000 |
| Warranty Distance UOM | DH |
| Warranty Time | 1 |
| Warranty Time UOM | YR |
| UPC | 00638217110146 |
FLEETGUARD LF767 Part Interchanges
| Brand | Part Number |
|---|---|
| Baldwin | B30 |
| GMC | 25010324, 25010276 |
| Champ | PH45 |
| Mopar | L322 |
| Donaldson | LFP550045, P550045, P550598, P779176 |
| Motorcraft | FL331 |
| Hastings | 230, LF230, P230 |
| Pennzoil | PZ10 |
| Group 7 | V123 |
| FRAM | DG3429, PH3429, PH3429A |
| Kralinator | L195 |
| Purolator | L20123, PER123 |
| Quaker State | QS3429 |
| Wix | 51045 |
| Big A | 2045, 92045 |
| Firestone | TF45 |
| Guardian | G051045 |
| LUBER-FINER | LFP45, PH45 |
| CARQUEST | 85045 |
| Caterpillar | 9Y4453 |
| Conoco | CN3429 |
| Cyclone | PM522 |
| Facet | 45 |
| John Deere | TY15134 |
| Hutchens | SF123 |
| M Filter | MH380 |
| Maste | DK94 |
| Phillips 66 | PO45 |
| Sears | 45178 |
| Sunoco | O14 |
| Texaco | T23, T23B |
| Lee | LF45 |
| Goodyear | 2224512 |
| Valvoline | VO14 |
| STP | S045 |
| MAHLE | OC69 |
| Atlas | G74 |
| Gulf | GF216 |
| NAPA | 1045 |
| AC | PF45 |
| Gonher | GP3429 |
| AMS | ASF30 |
| Autopar | FE174 |
FLEETGUARD LF767 Cross References
We have 5 alternatives for the LF767 by FLEETGUARD:
FLEETGUARD LF767 Customer Reviews
No reviews yet
Be the first to review this product!
FLEETGUARD LF767 Manufacturer Information
Since 1987, Fleetguard® has been one of the world's leaders in filtration solutions for both on- and off-highway applications. Whether it's air, fuel, oil, or hydraulic filtration, Fleetguard filters provide superior protection against contaminants for engines and sensitive equipment in the agriculture, construction, commercial vehicle, marine, mining, and power generation industries. Each filter is fitted with high-quality filter media for longer service life as well as a more compact design to accommodate shrinking engine compartments found in modern vehicles. All products also undergo extensive performance tests and strict quality control procedures to ensure durability and consistent performance, even in the most demanding operating conditions.
