PETERSON LIGHTING part description

146 2" Clearance and Side Marker Light

Peterson Lighting 2" Clearance & Side Marker Light

The Peterson Lighting 2" clearance & side marker light is designed to alert other drivers to a larger truck's presence on the road. When mounted at a 45-degree angle, it functions as a combination clearance and side marker light, allowing the driver to see another vehicle that is approaching at an angle at night.

Features & Benefits

  • Designed with a 15,000-hour long life bulb
  • With sealed lens and housing, which offers extra protection against damaging elements
  • Comes with flange for use with rubber grommet
  • Requires a 2-wire plug and mounting grommet in order to be installed
  • Available as a kit that contains 146 light, 146-18 grommet, and 142-49 plug
  • A premium replacement clearance/side marker light at a competitive price

Product Description

INCANDESCENT MARKER/CLEARANCE, PC, ROUND, KIT, 2"

Features & Benefits

  • Available in retail-friendly Viz Pack.
  • Features sealed lens and housing; 146F and 146S lights are sonic welded to flange to form single unit.
  • 146 light comes without flange for use with rubber grommet.
  • Requires 2-wire plug to complete installation.
  • Features 15,000-hour-rated long-life bulb.
  • Kit includes 146 light, 146-18 grommet and 142-49 plug.
  • ABS warning version avail., or see 2954 accessory ABS label on Peterson Master Catalog page 194.
  • See Peterson Master Catalog page 69 for LED versions.
  • See mounting accessory section for additional mounting options.
  • Made in USA.
  • LED version available.
  • Long life bulb.
  • Recommended for marine trailer use.
  • PC Rated.
  • Functions as side marker or clearance light.
  • May be used as combination side marker and clearance light when mounted at a 45° angle.

146-18: grommet (poly pack - std qty 24)

Product Attributes

Bulb Technology incandescent
Bulb/diode Count 1
California Proposition 65 Required Y
Container Type bulk pack
Diameter 2.25 IN
Family PM
Filament Quantity 1
Ground Type plug
Height 2.25 in
Integral Reflex N
Length 2.25 in
Lens Color red
Light Color red
Marine Use Y
Mounting Type grommet
Pc Rated Y
Regulatory Compliance DOT
Removable Lens N
Replaceable Bulb N
Shape 2-inch round
Termination PL10
Voltage 24 Volts
Width 0.9 in

Additional Information

Country of Origin (Primary) US
Harmonized Tariff Code (Schedule B) 8512202000
UPC 00044464966656
VMRS Code 034004021

Part Interchanges

PETERSON LIGHTING M146KR Cross Reference

We have 2 alternatives for the M146KR by PETERSON LIGHTING:

Peterson Lighting® is a family-owned company that produces and distributes vehicle safety lighting systems mirrors, and other related safety products and accessories. It has been in the business for 75 years, and currently, it offers over 2,200 products designed for various applications, including tilt-bed and cargo vehicles and light- and medium-duty trailers. Peterson Lighting believes that full commitment to quality is its responsibility as a market leader. All its components are designed and manufactured only in its ISO 9001/QS-9000-certified facility in Grandview, MO. This facility is handled by knowledgeable and highly skilled specialists, who are as dedicated and passionate as the company when it comes to quality.
