DELPHI TA3578 Part Description
Manufacturer
Product Description
Tie Rod End
Features & Benefits
- Delphi includes the necessary accessories for a complete job
- Delphi machines the ball studs to micron tolerances to guarantee durability and smooth joint operation
- Delphi tie rods are fatigue tested to avoid failure
- Anti Corrosion protection applied to each part for optimum corrosion prevention and enhanced aesthetics
Tie Rod End
DELPHI TA3578 Specifications
Product Attributes
| Color | Black |
| End 1 Gender | Male |
| End 2 Gender | Female |
| Finish | Painted |
| Pre-Greased | Yes |
| Grease Fitting Included | No |
| Dust Boot Included | Yes |
| Type | Bent |
| Mounting Hardware Included | Yes |
| End 2 Thread Diameter | 16.00 MM |
| Height | 92.90 MM |
| Grade Type | Standard Replacement |
| Housing Material | Steel |
| Adjustable | No |
| Greaseable | No |
| Weight | 2.13 lb |
| Cone Outside Diameter | 21.30 MM |
| Bearing Material | Polyoxymethylene (POM) |
| End 1 Thread Direction | Clockwise (Right) |
| End 2 Thread Direction | Clockwise (Right) |
| Grade | Premium |
| Stud Type | Threaded |
| Head Drive Type | Hex |
| End 2 Thread Pitch | 1.5 MM |
| End 1 Thread Pitch | 1.5 MM |
| Length - Stud Center to End | 207.00 MM |
| Dust Boot Material | Rubber |
| Tie Rod Material | Steel |
| End 1 Thread Diameter | 14.00 MM |
| Position(s) | Right Outer |
| End 2 Thread Diameter | 0.630 IN |
| Cone Outside Diameter | 0.839 IN |
| Length - Stud Center to End | 8.150 IN |
| End 1 Thread Diameter | 0.551 IN |
Additional Information
| Country of Origin (Primary) | TR |
| Harmonized Tariff Code (Schedule B) | 8708948000 |
| Harmonized Tariff Code (HTS) | 8708947550 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| UPC | 00689604394120 |
| VMRS Code | 015004019 |
| UNSPSC | 25174205 |
DELPHI TA3578 Cross References
| Brand | Part Number |
|---|---|
| N/A | ES810454, MS25655, 68364926AA, 68225 822AA |
DELPHI TA3578 Fits Vehicles
- Ram ProMaster 3500 (2014-2021)
- Ram ProMaster 2500 (2014-2021)
- Ram ProMaster 1500 (2014-2021)
