Name: Reach Cooling 61-1833 Charge Air Cooler
SKU: 611833
Price: 1262.99 USD
Availability: InStock

REACH COOLING part description

Charge Air Cooler

Product Description

Charge Air Cooler

Features & Benefits

Reinforcement Rib: Tubes feature a reinforcing rib to increase material strength.
Flat Tube Wall Thickness: Flat tube wall thickness is no less than .55mm to maximize ability to withstand added pressure.
Reinforced Aluminum Alloy: Header reinforced with aluminum bronze to increase strength by 50%.
7 Layer Packaging: Each charge air cooler is packaged in a heavy duty, 7 layer corrugated box to ensure best protection during transit.
REACH charge air coolers are built to withstand the pressures of long hauls. From the product design to the package it is shipped in, every consideration is taken to ensure longevity and peak performance.
Deep Extrusion Header: Our deep extrusion header provides a stronger tube to header joint which is more resistant to the effects of vibration and thermal tube expansion.
Header Plate Bond: We use a wider angle header plate bond to eliminate the risk of header cracking

Product Attributes

Type	Tube and Fin
Core Thickness	1 15/16 IN
Core Length	546.1 MM
Inlet Outside Diameter	103 MM
Outlet Location	Middle Right
Outlet Outside Diameter	4 1/16 IN
Inlet Location	Upper Left
Outlet Outside Diameter	103.2 MM
Core Length	21 1/2 IN
Core Thickness	49.2 MM
Core Material	Aluminum
Core Height	36 5/16 IN
Core Height	922.3 MM
Inlet Outside Diameter	4.062 IN
Outlet Outside Diameter	103

Part Interchanges

Fits Vehicles

Freightliner M2 106 (2003-2007)
Freightliner M2 (2005-2007)
