MEI 5811 Airsource A/C Compressor, R12

PRODUCT SPECIFICATIONS:

• Part No.: 5811
• OEM No.: 10325011, 10025011, 488-25011
• Manufacturer: Valeo
• Application: Multi Fit Applications
• Volts: 12V
• Clutch Diameter: 132mm
• No. of Grooves: 2 groove
• Belt Type: Two 1/2'' Belts
• No. Comp. Cylinders: 6 cyl
• Comp. Displacement (ci): 9.0 cu.in.
• Factory Oil Charge: 150cc Oil
• Fitting Port Position: Vertical
• Fitting Style: Pad w/A-style #8-#10 O-ring manifold
• Head Type: G - Univ Pad type
• Wire Type: 1 Wire bullet
• Replacement Clutch Assy.: 5076
• Replacement Head Assy: NSS
• Model: TM15
• Mounting Type: Ear mount
• Oil Type: Mineral
• Refrigerant Type: R12
• Rotation: CW/CCW
• O-Ring #1: 0013
• O-Ring #2: 0015
• Shaft Type: Splined shaft
• Notes: may be suplied with alum manifold-eff. 2016
• Diode Protection: None
• Manifold: 5590
