(888) 312-8812 Login SignupMERITOR 0415902003 Hub Assembly, 9.823 in. Disc Bolt Circle Diameter, 7.00 in. DriveStud Bolt Circle Diameter
MSRP: $1,803.28
$1,03599
Save $767.29
Limited availability at this price!
In Stock
Get it by Thursday, Aug 6
MERITOR 0415902003 Part Description
Manufacturer
Product Description
Hydraulic Brake, Hub And Stud Assembly
Features & Benefits
- Hub-and-stud assembly renews wheel mounting hardware in one service piece
- ABS tone ring provision keeps sensor reading tied to the hub location
- Bearing surfaces matter before the wheel end returns to load-bearing service
- Hydraulic brake setup receives a hub matched to disc brake mounting demands
- Eight-stud wheel position gains fresh fastening points after hub replacement
Meritor Hydraulic Brake Hub Assembly
The Meritor Hydraulic Brake Hub Assembly sits at the center of the wheel end, carrying the wheel mounting points while working with the bearing set and disc brake arrangement. Its hub-and-stud build feels substantial because the part has to handle wheel load, fastening torque, and brake hardware location together. Wheel-end repairs on hydraulic brake axles can reach the hub once the studs, bearing surfaces, or ABS-related hardware show service wear. During 26,000-pound GAWR hub service involving damaged studs, bearing-seat wear, or ABS tone ring concerns, the Meritor 0415902003 brings a new hub foundation into the hydraulic brake wheel end.
| ABS Pilot Diameter | Attaches to Rotor |
| ABS Ring Number | 09-002165 |
| Base Part Number | 15902 |
| Brake Type | DX |
| Disc Bolt Circle Diameter | 9.823 in. |
| Disc Bolt Pattern | 10 |
| Disc Bolt Size | .659/.679 in. |
| Drive Flange Stud | 08-008551 |
| Drive Stud Pattern | 8 |
| Drive Stud Thread | 5/8-11 UNC-3B |
| DriveStud Bolt Circle Dia | 7.00 in. |
| Flange Outer Diameter | 13.50 in. |
| GAWR (lb) | 26000 |
| IBS to OBS | 4.317/4.297 in. |
| IBS to Outer Surface | 6.902 in. |
| Inner Bearing Surface (IBS) to Mounting Face | 2.003 in. |
| Inner Cone | 594A |
| Inner Cup | 592A |
| Outer Cone | 580 |
| Outer Cup | 572 |
| Rotor Number | 3218Z1404 |
| Rotor Pilot Diameter | 7.637/7.634 in. |
| Tone Ring | Y |
| VMRS Code | 018-002-001 |
| Wheel Pilot Diameter | 8.653/8.646 in. |
| Wheel Stud | 09-001728 |
| Wheel Stud Bolt Circle Diameter | 11.25 in. |
| Wheel Stud Hole | .904/.906 in. |
| Wheel Stud Pattern | 10 |
Meritor Hydraulic Brake Hub and Stud Assembly
The Meritor hydraulic brake hub and stud assembly is built for higher payload capacities and improved fuel economy. It is suitable for a wide range of trucks, trailers, and other commercial vehicle applications.
Features & Benefits
- Designed for weight savings and strength for increased payload and better fuel mileage
- Meets or exceeds OE specifications and federal stopping distance requirements
- Advanced machining processes ensures an optimum balanced operation
- Studs are made of heat-treated steel for increased durability long service life
- Click here for warranty information
- Hub-and-stud assembly renews wheel mounting hardware in one service piece
- Eight-stud wheel position gains fresh fastening points after hub replacement
MERITOR 0415902003 Specifications
Product Attributes
| Abs Pilot Diameter | Attaches to Rotor |
| Brake Type | DX |
| Abs Ring Number | 09-002165 |
| Brand | Meritor |
| Disc Bolt Pattern | 10 |
| Disc Bolt Circle Diameter | 9.823 in. |
| Disc Bolt Size | .659/.679 in. |
| Flange Outer Diameter | 13.50 in. |
| Drive Stud Thread | 5/8-11 UNC-3B |
| DriveStud Bolt Circle Diameter | 7.00 in. |
| Tone Ring | Y |
| Rotor Pilot Diameter | 7.637/7.634 in. |
| Wheel Pilot Diameter | 8.653/8.646 in. |
| Wheel Stud Hole | .904/.906 in. |
| Wheel Stud Bolt Circle Diameter | 11.25 in. |
| Wheel Stud Pattern | 10 |
MERITOR 0415902003 Cross References
| Brand | Part Number |
|---|---|
| TDA0415902003, KM3066, 0515954005RI, 621617 |
