WABCO 911 153 020 R - Air Brake Compressor - Single Cylinder, for ISC/ISL Engine
$1,12699
+$437.50 Core Deposit
Total price w/ core: $1,564.49
Limited Availability
. Learn more
WABCO part description
Product Attributes
| Port Thread 0 | Ø 20.5 mm |
| Max. operating pressure | 10.0 bar |
| Calculated Volume (dm³) | 12.76 |
| Piston stroke | 2.20 in |
| Max. operating pressure | 145.0 psi |
| Piston Diameter | 85 mm |
| Operating speed | 3000 (1/min) |
| Swept Volume (Cm³) | 318 cm3 |
| Weight | 42 |
| Port Thread 9.2 | 3/4" - 16 UNF |
| Port Thread 9 | 3/4" - 16 UNF |
| Temperature Range | -40°C to +80°C |
| Lubrication | Lubrication supplied from engine |
| Size | 311 x 270 x 152 |
| Port thread 4 | M10 x 1.0 |
| Port Thread 9.1 | 3/4" - 16 UNF |
| Port thread 2 | M27 x 2 |
| Port thread 2 | M27 x 2 |
| Crankshaft thread | M20 x 1.5 |
| Mounting | Mounting Flange |
| Port Thread 8.1 | M10 x 1 |
| Mounting | Mounting Flange |
| Cooling | Water |
| Type | Single Cylinder |
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
