(888) 312-8812 Login SignupMERITOR A693276T20 Air Brake Chamber, 175.8 mm Outside Diameter, 8.00 in. Push Rod Length, Drum, 5/8" - 18 UNF, Threaded
Tap to view 5 more
MSRP: $485.39
$28899
Save $196.40
Limited availability at this price!
In Stock
Get it by Friday, Aug 21
MERITOR A693276T20 Part Description
Manufacturer
Product Description
Air Brake Chamber, Assembly
Meritor Type 20 Air Brake Chamber
The Meritor Type 20 Air Brake Chamber is a long-stroke S-cam drum brake service chamber with a 2.25-inch stroke and 8.00-inch push rod. Its 5/8-18 UNF thread, threaded clevis, and Type 20 model identity give brake service teams clear installation details before the chamber goes on the vehicle. The assembly belongs at the actuator position, where the chamber package must match the brake layout rather than the valve or shoe set. Meritor A693276T20 gives S-cam brake service a complete chamber assembly with defined rod, stroke, and thread specs.
| Application and General Information | S-Cam Brakes (Drum) Std Stroke - Service Chamber |
| Brake Type | S-Cam Brake (Drum) |
| Chamber Type | Service Chamber Standard Stroke |
| Length | 105.7mm |
| Model | 20 |
| Outside Diameter | 175.8 mm |
| Push Rod Length (Aftermarket) | 8.00 in. |
| Related Numbers | MGM Production # 1420213; MGM Aftermarket # 1420001 |
| Stroke | 2.25 in. |
| Thread Diameter | 5/8 - 18 UNF |
| VMRS Code | 013-004-036 |
Meritor Air Brake Chamber
The Meritor air brake chamber is designed for durability and long-term value. It is suitable for use with both truck and trailer applications.
Features & Benefits
- Double O-rings and bushings provide superior leak protection and wear resistance
- Premium-grade diaphragm lasts up to 1.2 million chamber life cycles and 500 thousand parking life cycles
- High-quality springs provides linear output with up to 500,000 parking life cycles
- Drawn arc stud welding construction creates a bond that’s stronger than the surrounding metal
- Type 20 chamber: identifies the actuator size for brake service
- Threaded clevis: provides the listed connection style at the rod end
- Converts air pressure into pushrod movement for S-cam brakes
- Serves drum brake repairs requiring the specified stroke and rod length
MERITOR A693276T20 Specifications
Product Attributes
| Application And General Information | S-Cam Brakes (Drum) Std Stroke - Service Chamber |
| Brake Type | Drum |
| Brand | Meritor |
| Chamber Type | Brake Chamber |
| Clevis | Threaded |
| Length | 105.7 mm |
| Model | Type 20 |
| Oe Mfg. | MGM |
| Outside Diameter | 175.8 mm |
| Pallet Quantity | 64 |
| Push Rod Length (aftermarket) | 8.00 in. |
| Related Numbers | MGM Production # 1420213; MGM Aftermarket # 1420001 |
| Stroke | 2.25 in. |
| Thread Diameter | 5/8" - 18 UNF |
| Weight | 7.58 |
| Chamber Type | Brake Chamber |
| Notes | S-Cam Brakes (Drum) Std Stroke - Service Chamber |
| Push Rod Length | 8.00 in. |
MERITOR A693276T20 Cross References
| Brand | Part Number |
|---|---|
| 8235A693276T20, TDAA693276T20 | |
| MGM BRAKES | 1420001, 1420213 |
