(888) 312-8812 Login SignupFRAM XG12447 Spin-on Oil Filter
Tap to view 4 more
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
FRAM XG12447 Part Description
Manufacturer
Product Description
FRAM, XG12447, Oil Filter
Features & Benefits
- Proven protection for up to 20,000 miles (32,000 kilometers)
- SureGrip® technology for easy install and removal
- Silicone anti-drain back valve helps ensure safe engine start up
- Dual-layered synthetic blend media provides 99%+ filtration efficiency*
- Optimized for synthetic motor oil
- SureGrip(R) technology for easy install and removal
Spin-on Oil Filter
Spin-on Oil Filter
FRAM XG12447 Specifications
Product Attributes
| Filter Media Material | Synthetic |
| Height | 3.11 IN |
| Anti-Drain Back Valve | Yes |
| Burst Pressure | 300 PS |
| Bypass Relief Valve | No |
| Filter Type | Spin-On Canister |
| Gasket Thickness | 0.45 IN |
| Housing Color | Gold |
| Non Slip Grip | No |
| Torque Nut | No |
| Gasket Inside Diameter | 2.39 IN |
| Gasket Outside Diameter | 2.76 IN |
| Attachment Type | Spin-On |
| Drain Plug Included | Yes |
| Gasket Type | Base |
| Grade | Ultimate |
| Grade Type | Premium |
| Inlet Type | Threaded |
| Inside Thread Diameter | 1-16 IN |
| Meets Or Exceeds Original Equipment Manufacturer Specifications | Yes |
| New Or Remanufactured | New |
| Outside Diameter | 2.942 IN |
| Replacable Filter | Yes |
| Reusable | No |
| Thread Size | Standard |
| Grade Type | Premium |
| Marine Approved | No |
| Inner Thread Diameter | 1-16 IN |
| Replaceable Filter | Yes |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (HTS) | 8421230000 |
| Warranty Special | See Rep |
| Warranty Special UOM | SR |
| Warranty Time | 30 |
| Warranty Time UOM | DA |
| UPC | 00009100576590 |
| UNSPSC | 15121501 |
FRAM XG12447 Cross References
| Brand | Part Number |
|---|---|
| ACDelco | PF66 |
| Carquest Premium Filters | 95146 |
| Champ | PH10066 |
| FRAM Tough Guard | TG12447 |
| FRAM Ultra Synthetic | XG12447 |
| General Motors | 12727115, 55495105 |
| K&N | HP-1021 |
| LUBER-FINER | PH10066 |
| Mighty Distributing System | M9510SP |
| Mobil | PH10066 |
| Motomaster OE Plus | MOPH12447 |
| NAPA Gold Filters | 100351 |
| PUROLATOR | TL11424, PL11424, PBL11424 |
| Parts Master | WL610351 |
| Premium Guard | PG99495 |
| Purolator | L11424 |
| STP Filters | S45008, S45008XL |
| Service Champ | OF1424 |
| Valvoline | VO-202 |
| WIX FILTERS | WL10351XP, WL10351 |
| Warner | WPH10066 |
| Warner Filters | WPH10066 |
| Wix | WL10351 |
FRAM XG12447 Fits Vehicles
- Suzuki Aerio (2002)
- Buick Enclave (2025-2026)
- Chevrolet Traverse (2024-2026)
- GMC Canyon (2023-2026)
- Chevrolet Colorado (2023-2026)
- Chevrolet Silverado 1500 LTD (2022)
- GMC Sierra 1500 Limited (2022)
- Buick Envision (2021-2026)
- Cadillac XT6 (2021-2025)
- Cadillac Escalade (2021-2024)
- Cadillac Escalade ESV (2021-2024)
- GMC Yukon (2021-2026)
- GMC Yukon XL (2021-2026)
- Chevrolet Suburban (2021-2026)
- Chevrolet Tahoe (2021-2026)
- Chevrolet Trailblazer (2021-2026)
- Buick Encore GX (2020-2026)
- Cadillac CT4 (2020-2026)
- Cadillac CT5 (2020-2026)
- Cadillac XT5 (2020-2026)
- Chevrolet Blazer (2020-2026)
- GMC Acadia (2020-2026)
- Cadillac XT4 (2019-2025)
- Cadillac CT6 (2019)
- GMC Sierra 1500 (2019-2026)
- Chevrolet Silverado 1500 (2019-2026)
FRAM XG12447 Customer Reviews
No reviews yet
Be the first to review this product!
FRAM XG12447 Manufacturer Information
FRAM® is all-set to "Filter out the Nonsense." With an origin that dates back to 1932, this brand has been globally recognized as the filter authority for its world-class filtering solutions that offer maximum engine protection, unparalleled filtering performance, and superior dirt-holding capacity. FRAM provides the industry with first-rate air filters, oil filters, heavy-duty commercial filters that help keep engines running efficiently, the way a well-filtered machine should. Among FRAM's popular products are the FRAM Extra Guard air filter, Fresh Breeze cabin air filter, Titanium oil filter, heavy-duty hydraulic, coolant, or fuel filters, and many others. Whether you are a fleet manager, a seasoned mechanic, or an experienced do-it-yourselfer, FRAM will provide you with filters that deliver efficiency, quality, reliability, performance, and durability at competitive prices.
FRAM XG12447 Questions & Answers
No questions yet
Be the first to ask a question about this product!
