(888) 312-8812 Login SignupRAYBESTOS 780139 Raybestos Specialty - Truck Brake Rotor
MSRP: $274.82
$20899
Save $65.83
Limited availability at this price!
In Stock
Get it by Friday, Sep 11
RAYBESTOS 780139 Part Description
Manufacturer
Product Description
Raybestos Specialty - Truck Brake Rotor
Application Summary
2008-2003 Dodge Ram 2500 Rear, 2008-2006 Dodge Ram 1500 Rear, 2008-2003 Dodge Ram 3500 Rear, 2008-2005 Dodge Ram 4000 Rear
Features & Benefits
- OE Fit, Form, and Function
- Our vehicle-specific design matches OE fit, form and function, providing ultimate strength and performance
- Cooling Vanes
- We dedicate time to match the cooling vanes on our Specialty rotors to OE designs, ensuring: Optimal cooling Reduced fade Less noise Increased pad life
- Coating
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0® rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0(R) rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- SAE Standard for Tensile Strength
- Our rotors follow SAE standards for tensile strength, hardness, and iron grade, providing structural integrity and maximum service life
- Turned Finish
- A turned finish provides an excellent surface for the pads to engage with to ensure a smooth and effective stop right out of the box
RAYBESTOS 780139 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 4.84 IN |
| Center Hole Diameter | 122.95 MM |
| Conventional Or Drum-In-Hat Type Rotor | Drum-In-Hat |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 1.118 IN |
| Discard Thickness | 28.4 MM |
| Harmonize Code | 8708.30.5030 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 6.5 IN |
| Mounting Bolt Hole Circle Diameter | 165.1 MM |
| Mounting Bolt Hole Diameter | 0.667 IN |
| Mounting Bolt Hole Diameter | 16.95 MM |
| Mounting Bolt Hole Quantity | 8 |
| Nominal Thickness | 1.185 IN |
| Nominal Thickness | 30.1 MM |
| Outside Diameter | 13.855 IN |
| Outside Diameter | 351.9 MM |
| Overall Height | 5.15 IN |
| Overall Height | 130.8 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Solid |
| Stud/Lug Hole Quantity | 8 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352205051 |
RAYBESTOS 780139 Cross References
| Brand | Part Number |
|---|---|
| 78072090, 829352205051 | |
| ADVANCE AUTO PARTS | 145452, YH145452, YH145452C, YH145452P |
| AUTOXTRA | AX53011 |
| AUTOZONE | 53011, 53011DG, DL53011 |
| AutoZone | 53011SD |
| BENDIX | 145452 |
| BRAKEBEST | 16010170, 780139, 780139FZN, 780139PER, 780139R, 780139RGS, 81-126049, BD126049 |
| BREMBO | 09.B655.10, 27385 |
| CENTRIC | 120.67062, 120.67062CRY, 121.67062, 125.67062, 125.67062CRY, 126.67062CSL, 126.67062CSR, 126.67062SL, 126.67062SR, 127.67062CL, 127.67062CR, 127.67062L, 127.67062R, 128.67062CL, 128.67062CR, 128.67062L, 128.67062R, 227.67062L, 227.67062R, 320.67062, 320.67062F, 321.67062 |
| CHRYSLER | 05083728AA, 5083728AA, 52010144AA |
| Casting Numbers | 0204212035, 211476-C, 325610 |
| Centric Parts | 120.67062, 120.67062CRY, 121.67062, 125.67062, 125.67062CRY, 126.67062CSL, 126.67062CSR, 126.67062SL, 126.67062SR, 127.67062CL, 127.67062CR, 127.67062L, 127.67062R, 128.67062CL, 128.67062CR, 128.67062L, 128.67062R, 227.67062L, 227.67062R, 320.67062, 320.67062F, 321.67062 |
| DURA CORP | BR53011, BR5301102 |
| DuraGo | BR53011, BR5301102, BR53011-02 |
| EUCLID | E-12397 |
| MAGMA PRODUCTS | PSR145167 |
| MIGHTY DISTRIBUTING SYSTEM | 53011 |
| MONROE BRAKES | BD126049 |
| NEOTEK | 107070GF |
| NEWTEK AUTOMOTIVE | 53011 |
| Newtek Automotive USA | 53011 |
| Omnicraft | QBRR185 |
| POWERSTOP | AR8772EVC |
| PROMAX | 14-53011 |
| PRONTO | BR53011 |
| QUALIS | 53011 |
| QUALITY BRAND | Q4185 |
| TopNotch | TN780139GEO |
| UAP | 2053011, 53011 |
| Ultra Brake | 53261 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X51527 |
| WABCO | PS126049 |
| WABCO - Archived | PS126049 |
| WAGNER | BD126049E, BD126049 |
| WAGNER BRAKE | BD126049, BD126049E |
| WINHERE | 6620234 |
| WORLDPAC | 1407-25861, 1427-731989 |
RAYBESTOS 780139 Fits Vehicles
- Dodge Ram 4000 (2005-2008)
- Dodge Ram 1500 (2006-2008)
- Dodge Ram 3500 (2003-2008)
- Dodge Ram 2500 (2003-2008)
