RAYBESTOS 56496 Raybestos Specialty - Truck Brake Rotor

★★★★★ (0)
Raybestos 56496 Disc Brake Rotor Raybestos Specialty - Truck Brake Rotor
RAYBESTOS

$199.49

Limited availability at this price!

In Stock

Get it by Wednesday, Sep 2
No Hassle Return Policy Details
Free Ground shipping on orders over $499 details

RAYBESTOS 56496 Part Description

Manufacturer

RAYBESTOS

Product Description

Raybestos Specialty - Truck Brake Rotor

Application Summary

2002-1994 Chevrolet C3500HD Front, 2002-1994 GMC C3500HD Front, 1999-1997 Chevrolet P30 Front, 2005-1999 Workhorse Custom Chassis P42 Front, 1999-1997 GMC P3500 Front, 2000 Workhorse P30 Front, 2005-1999 Workhorse P42 Front

Features & Benefits

  • OE Fit, Form, and Function
  • Our vehicle-specific design matches OE fit, form and function, providing ultimate strength and performance
  • Cooling Vanes
  • We dedicate time to match the cooling vanes on our Specialty rotors to OE designs, ensuring: Optimal cooling Reduced fade Less noise Increased pad life
  • Coating
  • All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0® rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
  • All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0(R) rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
  • SAE Standard for Tensile Strength
  • Our rotors follow SAE standards for tensile strength, hardness, and iron grade, providing structural integrity and maximum service life
  • Turned Finish
  • A turned finish provides an excellent surface for the pads to engage with to ensure a smooth and effective stop right out of the box

RAYBESTOS 56496 Specifications

Product Attributes

ABS Tone Ring Included No
Center Hole Diameter 5.005 IN
Center Hole Diameter 127.15 MM
Conventional Or Drum-In-Hat Type Rotor Conventional
Discard Thickness 1.366 IN
Discard Thickness 34.7 MM
Harmonize Code 8708.30.5030
Mounting Bolt Hole Circle Diameter 6.339 IN
Mounting Bolt Hole Circle Diameter 161 MM
Mounting Bolt Hole Diameter 6.339 IN
Mounting Bolt Hole Diameter 161 MM
Mounting Bolt Hole Quantity 5
Nominal Thickness 1.43 IN
Nominal Thickness 36.3 MM
Outside Diameter 13.85 IN
Outside Diameter 351.8 MM
Overall Height 2.935 IN
Overall Height 74.55 MM
Salability Restrictions No
Solid Or Vented Type Rotor Vented
Stud/Lug Hole Quantity 5
UNSPSC Code 25171715

Additional Information

Country of Origin (Primary) CN
Canadian Harmonizing Tariff Code 8708309990
Harmonized Tariff Code (HTS) 8708305030
UPC 00030999870391

RAYBESTOS 56496 Cross References

BrandPart Number
ACDELCO177-762
ADVANCE AUTO PARTS145027, YH145027
AMERICAN REMANUFACTURED789-44031, 89-44031
AUTOSPECIALTYAR8631, AR8631E
AUTOXTRA125639, 8056496, AX55029
AUTOZONE55029
BENDIX145027
BRAKE HEADQUARTERSBR55742
BRAKEBEST56496, 56496R, 56496RGS, BD125639
BREMBO09.8829.85, 27218, A-6012
CALIFORNIA DRUM & ROTOR125478, 125639
CENTRIC120.66031, 121.66031, 125.66031, 126.66031SL, 126.66031SR, 127.66031CL, 127.66031CR, 127.66031L, 127.66031R, 320.66031, 320.66031F
Casting Numbers210647-C, 211533-DP, 325421
Centric Parts120.66031, 121.66031, 125.66031, 126.66031SL, 126.66031SR, 127.66031CL, 127.66031CR, 127.66031L, 127.66031R, 320.66031, 320.66031F
DELPHIRB615
DURA CORPBR55029
DuraGoBR55029
EIS BRAKESD17744
EUROROTOR55762
FORMULA BLUE HYDRAULIC BRAKE PARTSE12571036
GM12547509, 15024282, 18028286
GREN671302
General Motors12547509, 15024282, 18028286
MAGMA PRODUCTSPSR227299
MIGHTY DISTRIBUTING SYSTEM55029
NEWTEK AUTOMOTIVE55029
Newtek Automotive USA55029
OmnicraftQBRR535
PEP BOYS55029G
PROMAX14-55029
PRONTOBR55029
QUALIS55029
QUALITY BRAND55029, Q4071
STANDARD ROTORS AND DRUMS55029
THE UNIVERSAL GROUP101461
UAP55029
Universal101461
VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURINGX51031
WABCOPS125639
WABCO - ArchivedPS125639
WAGNERBD125639, BD125639E
WAGNER BRAKEBD125478, BD125639
WINHERE442620, YH2620
WORKHORSEW8810506
Wagner BrakeBD125639E

RAYBESTOS 56496 Fits Vehicles

  • GMC C3500 (1995-2000)
  • Workhorse Custom Chassis P42 (1999-2005)
  • Workhorse Custom Chassis P32 (1999-2007)
  • GMC C3500HD (1994-2002)
  • Chevrolet C3500HD (1994-2002)
  • Workhorse W42 (2004-2005)
  • Workhorse P42 (1999-2005)
  • Workhorse P32 (1999-2005)
  • Workhorse P30 (2000-2005)
  • GMC P3500 (1997-1999)
  • Chevrolet P30 (1997-1999)
