RAYBESTOS 980005 Part Description
Manufacturer
Product Description
Raybestos Specialty - Street Performance Brake Rotor
Application Summary
2004-2000 Audi A6 Quattro Front, 2004-2002 Audi A6 Front, 2003-2002 Audi S6 Front
Features & Benefits
- Application Specific Enhanced Iron
- Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Cooling Vanes
- The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
- Application Specific Coating
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
- Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
- Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
- Turned Finish
- Turned finish minimizes noise and improves responsiveness for smoother stops.
- S-Groove Slot
- Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
- Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.
RAYBESTOS 980005 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.677 IN |
| Center Hole Diameter | 68 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 1.102 IN |
| Discard Thickness | 28 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 4.409 IN |
| Mounting Bolt Hole Circle Diameter | 112 MM |
| Mounting Bolt Hole Diameter | 4.409 IN |
| Mounting Bolt Hole Diameter | 112 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.181 IN |
| Nominal Thickness | 30 MM |
| Outside Diameter | 12.632 IN |
| Outside Diameter | 320.85 MM |
| Overall Height | 2.067 IN |
| Overall Height | 52.5 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | DE |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352221822 |
RAYBESTOS 980005 Cross References
| Brand | Part Number |
|---|---|
| 829352221822, 120.33065 | |
| ADVANCE AUTO PARTS | 141945, YH145555, YH145555C |
| ATE BRAKE PRODUCTS | SP30174, 430174 |
| AUTOXTRA | 8098005, AX34229 |
| AUTOZONE | 34229, 34229DG |
| BENDIX | 145555 |
| BRAKEBEST | 980005, 980005R, 980005RGS |
| BREMBO | 09.B440.10, 25703 |
| CENTRIC | 120.33065, 121.33065, 125.33065, 125.33065CRY, 126.33065CSL, 126.33065CSR, 126.33065SL, 126.33065SR, 127.33065L, 127.33065R, 128.33065CL, 128.33065CR, 128.33065L, 128.33065R |
| Casting Numbers | 211364-C, 326198, 4B3615301 |
| Centric Parts | 120.33065, 121.33065, 125.33065, 125.33065CRY, 126.33065CSL, 126.33065CSR, 126.33065SL, 126.33065SR, 127.33065L, 127.33065R, 128.33065CL, 128.33065CR, 128.33065L, 128.33065R |
| DURA CORP | BR34229 |
| DuraGo | BR34229, BR34275 |
| Dynamic Friction Company | 604-73023 |
| MIGHTY DISTRIBUTING SYSTEM | 34229 |
| NEOTEK | 1060117GF |
| NEWTEK AUTOMOTIVE | 34229 |
| Newtek Automotive USA | 34229 |
| PILENGA | V237 |
| PROMAX | 14-34229 |
| PRONTO | BR34229 |
| QUALIS | 34229 |
| TRW | 6060 |
| UAP | 34229 |
| VAICO | V1080074 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X51567 |
| VOLKSWAGEN | 4B3615301 |
| WAGNER | BD126105 |
| WAGNER BRAKE | BD126105 |
| WINHERE | 4420337 |
RAYBESTOS 980005 Fits Vehicles
- Audi S6 (2002-2003)
- Audi A6 (2000-2004)
- Audi A6 Quattro (2000-2004)
