(888) 312-8812 Login SignupRAYBESTOS 580381 Raybestos Specialty - Street Performance Brake Rotor
$16799
Limited availability at this price!
In Stock
Get it by Wednesday, Aug 5
RAYBESTOS 580381 Part Description
Manufacturer
Product Description
Raybestos Specialty - Street Performance Brake Rotor
Application Summary
2008-2005 Pontiac Grand Prix Front
Features & Benefits
- Application Specific Enhanced Iron
- Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Cooling Vanes
- The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
- Application Specific Coating
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
- Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
- Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
- Turned Finish
- Turned finish minimizes noise and improves responsiveness for smoother stops.
- S-Groove Slot
- Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
- Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.
RAYBESTOS 580381 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.783 IN |
| Center Hole Diameter | 70.7 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 1.181 IN |
| Discard Thickness | 30 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 4.528 IN |
| Mounting Bolt Hole Circle Diameter | 115 MM |
| Mounting Bolt Hole Diameter | 0.565 IN |
| Mounting Bolt Hole Diameter | 14.35 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.261 IN |
| Nominal Thickness | 32.05 MM |
| Outside Diameter | 12.718 IN |
| Outside Diameter | 323.05 MM |
| Overall Height | 2.046 IN |
| Overall Height | 51.95 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352498200 |
RAYBESTOS 580381 Cross References
| Brand | Part Number |
|---|---|
| ASH25846, 829352498200 | |
| ACDELCO | 177-0922 |
| ADVANCE AUTO PARTS | YH145737, YH145737C, YH145737P |
| AUTOZONE | 41222, 41222DG |
| BENDIX | PRT5737 |
| BOSCH | 25011476 |
| BRAKEBEST | 25011476, 580381, 580381RGS |
| CENTRIC | 120.62091, 121.62091, 128.62091, 228.62091, 320.62091, 320.62091F |
| Centric Parts | 120.62091, 121.62091, 128.62091, 228.62091, 320.62091, 320.62091F |
| DURA CORP | BR55121, BR900502 |
| DuraGo | 900502, BR900502 |
| GM | 15919061, 88965592 |
| General Motors | 15919061, 88965592 |
| NEOTEK | 1072064GF |
| NEWTEK AUTOMOTIVE | 55121 |
| Newtek Automotive USA | 55121 |
| PROMAX | 14-55121 |
| PRONTO | BR900502 |
| Qualis | 41222 |
| UAP | 55121 |
| WAGNER | BD126309 |
| WAGNER BRAKE | BD126309 |
| WINHERE | 6620712DR |
RAYBESTOS 580381 Fits Vehicles
- Mercedes-Benz GLE450 (2019-2022)
- Pontiac Grand Prix (2005-2008)
