(888) 312-8812 Login SignupRAYBESTOS 680181 Raybestos Specialty - Truck Brake Rotor
$6149
Limited availability at this price!
1 Day Lead Time
Get it by Monday, Aug 17
RAYBESTOS 680181 Part Description
Manufacturer
Product Description
Raybestos Specialty - Truck Brake Rotor
Application Summary
2008-2004 Ford F-150 Front, 2008-2006 Lincoln Mark LT Front, 2008-2004 Ford Lobo Front
Features & Benefits
- OE Fit, Form, and Function
- Our vehicle-specific design matches OE fit, form and function, providing ultimate strength and performance
- Cooling Vanes
- We dedicate time to match the cooling vanes on our Specialty rotors to OE designs, ensuring: Optimal cooling Reduced fade Less noise Increased pad life
- Coating
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0® rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0(R) rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- SAE Standard for Tensile Strength
- Our rotors follow SAE standards for tensile strength, hardness, and iron grade, providing structural integrity and maximum service life
- Turned Finish
- A turned finish provides an excellent surface for the pads to engage with to ensure a smooth and effective stop right out of the box
RAYBESTOS 680181 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 3.547 IN |
| Center Hole Diameter | 90.1 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 1.122 IN |
| Discard Thickness | 28.5 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 5.906 IN |
| Mounting Bolt Hole Circle Diameter | 150 MM |
| Mounting Bolt Hole Diameter | 0.602 IN |
| Mounting Bolt Hole Diameter | 15.3 MM |
| Mounting Bolt Hole Quantity | 7 |
| Nominal Thickness | 1.18 IN |
| Nominal Thickness | 29.95 MM |
| Outside Diameter | 12.99 IN |
| Outside Diameter | 329.95 MM |
| Overall Height | 1.885 IN |
| Overall Height | 47.9 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 7 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00747730872193 |
RAYBESTOS 680181 Cross References
| Brand | Part Number |
|---|---|
| 77416713, 747730872193 | |
| ADVANCE AUTO PARTS | 145544, YH145544, YH145544C, YH145544P |
| AUTOXTRA | 80680181, AX54110 |
| AUTOZONE | 54110, 54110DG |
| BENDIX | 145544 |
| BRAKEBEST | 20010381, 680181, 680181FZN, 680181PER, 680181R, 680181RGS, 81-126112, BD126112 |
| BREMBO | 27364, 09.B597.21 |
| CENTRIC | 120.65101, 121.65101, 126.65101CSL, 126.65101CSR, 126.65101SL, 126.65101SR, 127.65101CL, 127.65101CR, 127.65101L, 127.65101R, 128.65101L, 128.65101R, 320.65101, 320.65101F |
| Casting Numbers | 211579-C, 326003 |
| Centric Parts | 120.65101, 121.65101, 126.65101CSL, 126.65101CSR, 126.65101SL, 126.65101SR, 127.65101CL, 127.65101CR, 127.65101L, 127.65101R, 128.65101L, 128.65101R, 320.65101, 320.65101F |
| DURA CORP | BR54110 |
| DuraGo | BR54110 |
| FORD | 4L3Z1125BA, 4L3Z1125BC, 5L3Z1125BA |
| MAGMA PRODUCTS | PSR205215 |
| MIGHTY DISTRIBUTING SYSTEM | 54110 |
| MONROE BRAKES | BD126112 |
| MOTORCRAFT | BRR122 |
| NEOTEK | 1071027GF |
| NEWTEK AUTOMOTIVE | 54110 |
| Newtek Automotive USA | 54110 |
| PROMAX | 14-54110 |
| PRONTO | BR54110 |
| QUALIS | 54110 |
| QUALITY BRAND | Q4201 |
| STANDARD ROTORS AND DRUMS | 54110 |
| UAP | 54110 |
| Ultra Brake | 54294 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X51549 |
| WABCO | PS126112 |
| WABCO - Archived | PS126112 |
| WAGNER | BD126112, BD126112E |
| WAGNER BRAKE | BD126112 |
| WINHERE | 6620283 |
| Wagner Brake | BD126112E |
RAYBESTOS 680181 Fits Vehicles
- Ford F-150 Heritage (2004)
- Ford Lobo (2004-2008)
- Lincoln Mark LT (2006-2008)
- Ford F-150 (2004-2008)
