(888) 312-8812 Login SignupRAYBESTOS 980635 Raybestos Specialty - Truck Brake Rotor
$139.28
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
RAYBESTOS 980635 Part Description
Manufacturer
Product Description
Raybestos Specialty - Truck Brake Rotor
Application Summary
2012-2007 Hyundai Veracruz Front
Features & Benefits
- OE Fit, Form, and Function
- Our vehicle-specific design matches OE fit, form and function, providing ultimate strength and performance
- Cooling Vanes
- We dedicate time to match the cooling vanes on our Specialty rotors to OE designs, ensuring: Optimal cooling Reduced fade Less noise Increased pad life
- Coating
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0® rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0(R) rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- SAE Standard for Tensile Strength
- Our rotors follow SAE standards for tensile strength, hardness, and iron grade, providing structural integrity and maximum service life
- Turned Finish
- A turned finish provides an excellent surface for the pads to engage with to ensure a smooth and effective stop right out of the box
RAYBESTOS 980635 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.713 IN |
| Center Hole Diameter | 68.9 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 1.04 IN |
| Discard Thickness | 26.4 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 4.5 IN |
| Mounting Bolt Hole Circle Diameter | 114.3 MM |
| Mounting Bolt Hole Diameter | 4.5 IN |
| Mounting Bolt Hole Diameter | 114.3 MM |
| Nominal Thickness | 1.1 IN |
| Nominal Thickness | 27.95 MM |
| Outside Diameter | 12.638 IN |
| Outside Diameter | 321 MM |
| Overall Height | 1.941 IN |
| Overall Height | 49.3 MM |
| Salability Restrictions | No |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352637265 |
RAYBESTOS 980635 Cross References
| Brand | Part Number |
|---|---|
| CN5020RM, 829352637265 | |
| ADVANCE AUTO PARTS | YH200460, YH200460C, YH200460P |
| AUTOPARTSOURCE | 483220 |
| AUTOXTRA | AX900450 |
| AUTOZONE | 44597, 44597DG |
| BENDIX | PRT5775 |
| BRAKEBEST | 980635, 980635FZN, 980635R, 980635RGS |
| CENTRIC | 120.51026, 121.51026, 126.51026CSL, 126.51026CSR, 126.51026SL, 126.51026SR, 127.51026L, 127.51026R, 320.51026 |
| Casting Numbers | 326406 |
| Centric Parts | 120.51026, 121.51026, 126.51026CSL, 126.51026CSR, 126.51026SL, 126.51026SR, 127.51026L, 127.51026R, 320.51026 |
| DURA CORP | BR31510, BR900450 |
| DuraGo | 60444, 900450, BR60444, BR900450 |
| Hyundai | 517123J000, 517123J010 |
| NEOTEK | 1069002GF |
| NEWTEK AUTOMOTIVE | 31510 |
| Newtek Automotive USA | 31510 |
| PROMAX | 14-31510 |
| PRONTO | BR900450 |
| Qualis | 44597 |
| Ultra Brake | HY-362 |
| WAGNER | BD126512, BD126512E |
| WAGNER BRAKE | BD126527, BD126527E |
| WINHERE | 6620776 |
| WORLDPAC | 1407-75758 |
RAYBESTOS 980635 Fits Vehicles
- Hyundai Veracruz (2007-2012)
