RAYBESTOS 780258 Part Description
Manufacturer
Product Description
Raybestos Specialty - Truck Brake Rotor
Application Summary
2012-2005 Dodge Dakota Front, 2009-2006 Mitsubishi Raider Front, 2011 Ram Dakota Front
Features & Benefits
- OE Fit, Form, and Function
- Our vehicle-specific design matches OE fit, form and function, providing ultimate strength and performance
- Cooling Vanes
- We dedicate time to match the cooling vanes on our Specialty rotors to OE designs, ensuring: Optimal cooling Reduced fade Less noise Increased pad life
- Coating
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0® rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0(R) rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- SAE Standard for Tensile Strength
- Our rotors follow SAE standards for tensile strength, hardness, and iron grade, providing structural integrity and maximum service life
- Turned Finish
- A turned finish provides an excellent surface for the pads to engage with to ensure a smooth and effective stop right out of the box
RAYBESTOS 780258 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 3.09 IN |
| Center Hole Diameter | 78.5 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 1.024 IN |
| Discard Thickness | 26 MM |
| Harmonize Code | 8708.30.5030 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 5.5 IN |
| Mounting Bolt Hole Circle Diameter | 139.7 MM |
| Mounting Bolt Hole Diameter | 0.651 IN |
| Mounting Bolt Hole Diameter | 16.55 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.102 IN |
| Nominal Thickness | 28 MM |
| Outside Diameter | 12.28 IN |
| Outside Diameter | 311.9 MM |
| Overall Height | 2.6 IN |
| Overall Height | 66.05 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352332139 |
RAYBESTOS 780258 Cross References
| Brand | Part Number |
|---|---|
| 82276389, 829352332139 | |
| ADVANCE AUTO PARTS | 145617, YH145617, YH145617C, YH145617P |
| AUTOPARTSOURCE | 491075 |
| AUTOXTRA | 80780258, AX53025 |
| AUTOZONE | 53025, 53025DG |
| Autoxtra | AX53025P |
| BENDIX | 145617 |
| BOSCH | 16010231 |
| BRAKEBEST | 16010231, 780258, 780258FZN, 780258R, 780258RGS, BD126299 |
| BREMBO | 09.B657.10, 27411 |
| Brembo | 09.B657.11 |
| Bridgestone | 7009743 |
| CENTRIC | 120.67065, 121.67065, 126.67065CSL, 126.67065CSR, 126.67065SL, 126.67065SR, 127.67065L, 127.67065R, 227.67065L, 227.67065R, 320.67065, 320.67065F, 321.67065 |
| CHRYSLER | 52855005AB |
| Casting Numbers | 211654-C, 326208 |
| Centric Parts | 120.67065, 121.67065, 126.67065CSL, 126.67065CSR, 126.67065SL, 126.67065SR, 127.67065L, 127.67065R, 227.67065L, 227.67065R, 320.67065, 320.67065F, 321.67065 |
| DURA CORP | BR53025, BR5302502 |
| DuraGo | BR53025, BR5302502 |
| MAGMA PRODUCTS | PSR145175 |
| MIGHTY DISTRIBUTING SYSTEM | 53025 |
| MONROE BRAKES | BD126299 |
| NEOTEK | 107076GF |
| NEWTEK AUTOMOTIVE | 53025 |
| Newtek Automotive USA | 53025 |
| Omnicraft | QBRR156 |
| POWERSTOP | AR8763EVC |
| PROMAX | 14-53025 |
| PRONTO | BR53025 |
| QUALIS | 53025 |
| TopNotch | TN780258GEO |
| UAP | 2053025, 53025 |
| Ultra Brake | 53336 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X51721 |
| WABCO | PS126299 |
| WABCO - Archived | PS126299 |
| WAGNER | BD126299E, BD126299 |
| WAGNER BRAKE | BD126299, BD126299E |
| WINHERE | 6620509 |
| WORLDPAC | 1407-24194 |
RAYBESTOS 780258 Fits Vehicles
- Ram Dakota (2011)
- Mitsubishi Raider (2006-2009)
- Dodge Dakota (2005-2012)
