RAYBESTOS 680014 Part Description
Manufacturer
Product Description
Raybestos Specialty - Truck Brake Rotor
Application Summary
2005-2002 Ford Explorer Front, 2005-2002 Mercury Mountaineer Front
Features & Benefits
- OE Fit, Form, and Function
- Our vehicle-specific design matches OE fit, form and function, providing ultimate strength and performance
- Cooling Vanes
- We dedicate time to match the cooling vanes on our Specialty rotors to OE designs, ensuring: Optimal cooling Reduced fade Less noise Increased pad life
- Coating
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0® rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0(R) rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- SAE Standard for Tensile Strength
- Our rotors follow SAE standards for tensile strength, hardness, and iron grade, providing structural integrity and maximum service life
- Turned Finish
- A turned finish provides an excellent surface for the pads to engage with to ensure a smooth and effective stop right out of the box
RAYBESTOS 680014 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 3.23 IN |
| Center Hole Diameter | 82.05 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 0.965 IN |
| Discard Thickness | 24.5 MM |
| Harmonize Code | 8708.30.5030 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 4.5 IN |
| Mounting Bolt Hole Circle Diameter | 114.3 MM |
| Mounting Bolt Hole Diameter | 0.546 IN |
| Mounting Bolt Hole Diameter | 13.85 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.025 IN |
| Nominal Thickness | 26.05 MM |
| Outside Diameter | 12.02 IN |
| Outside Diameter | 305.3 MM |
| Overall Height | 2.21 IN |
| Overall Height | 56.15 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00747730234076 |
RAYBESTOS 680014 Cross References
| Brand | Part Number |
|---|---|
| 6360-525, 747730234076 | |
| ADVANCE AUTO PARTS | 145311, N1000124838APO, YH145311, YH145311C, YH145311P |
| AMERICAN REMANUFACTURED | 89-42090, 89-42091 |
| AUTOPARTSOURCE | 592385 |
| AUTOSPECIALTY | AR8589, AR8589E |
| AUTOXTRA | AX54094 |
| AUTOZONE | 54094, 54094DG, 54094DL, DL54094 |
| BENDIX | 145311 |
| BOSCH | RBR54094 |
| BRAKEBEST | 680014, 680014FZN, 680014R, 680014RGS, 81-125758, BD125758 |
| BREMBO | 09.8972.10, 09.8972.85, 27235 |
| Brembo | 09.8972.11 |
| CENTRIC | 120.65091, 121.65091, 125.65091, 125.65091CRY, 126.65091CSL, 126.65091CSR, 126.65091SL, 126.65091SR, 127.65091CL, 127.65091CR, 127.65091L, 127.65091R, 128.65091CL, 128.65091CR, 128.65091L, 128.65091R, 227.65091L, 227.65091R, 320.65091, 321.65091 |
| CONTINENTAL-CONTITECH | CW26720 |
| Casting Numbers | 211371-C, 2539603, 325536 |
| Centric Parts | 120.65091, 121.65091, 125.65091, 125.65091CRY, 126.65091CSL, 126.65091CSR, 126.65091SL, 126.65091SR, 127.65091CL, 127.65091CR, 127.65091L, 127.65091R, 128.65091CL, 128.65091CR, 128.65091L, 128.65091R, 227.65091L, 227.65091R, 320.65091, 321.65091 |
| DURA CORP | BR54094, BR5409402 |
| DuraGo | BR54094, BR5409402, BR54094-02 |
| FORD | 1L2Z1102AC, 1L2Z1125AA, 4L2Z1102AC, 4L2Z1125AA, 3L2Z1125BA |
| FORMULA BLUE HYDRAULIC BRAKE PARTS | E12570096 |
| GREN | 627502 |
| GUARDIAN | 52-125758 |
| MAGMA PRODUCTS | PSR205200 |
| MIGHTY DISTRIBUTING SYSTEM | 54094 |
| MONROE BRAKES | BD125758 |
| MOTORCRAFT | BRR98 |
| NEOTEK | 1071001GF |
| NEWTEK AUTOMOTIVE | 54094 |
| Newtek Automotive USA | 54094 |
| POWERSTOP | AR8589EVC |
| PROMAX | 14-54094 |
| PRONTO | BR54094 |
| QUALIS | 54094 |
| QUALITY BRAND | 54094, Q4098, Q4101 |
| STANDARD ROTORS AND DRUMS | 54094 |
| THE UNIVERSAL GROUP | 102120 |
| UAP | 54094 |
| Ultra Brake | 54190 |
| Universal | 102120 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X51367 |
| WABCO | PS125758 |
| WABCO - Archived | PS125758 |
| WAGNER | BD125758, BD125758E |
| WAGNER BRAKE | BD125758, BD125758E |
| WINHERE | 662779, YH2779 |
| WORLDPAC | 1407-25761 |
RAYBESTOS 680014 Fits Vehicles
- Mercury Mountaineer (2002-2005)
- Ford Explorer (2002-2005)
