RAYBESTOS 580547 Part Description
Manufacturer
Product Description
Raybestos Specialty - Truck Brake Rotor
Application Summary
2009-2007 Chevrolet Equinox Front, 2015-2011,2008 Chevrolet Captiva Sport Front, 2010-2008 Saturn Vue Front, 2009-2007 Pontiac Torrent Front, 2009-2007 Suzuki XL-7 Front
Features & Benefits
- OE Fit, Form, and Function
- Our vehicle-specific design matches OE fit, form and function, providing ultimate strength and performance
- Cooling Vanes
- We dedicate time to match the cooling vanes on our Specialty rotors to OE designs, ensuring: Optimal cooling Reduced fade Less noise Increased pad life
- Coating
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0® rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0(R) rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- SAE Standard for Tensile Strength
- Our rotors follow SAE standards for tensile strength, hardness, and iron grade, providing structural integrity and maximum service life
- Turned Finish
- A turned finish provides an excellent surface for the pads to engage with to ensure a smooth and effective stop right out of the box
RAYBESTOS 580547 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.783 IN |
| Center Hole Diameter | 70.7 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 1.079 IN |
| Discard Thickness | 27.4 MM |
| Harmonize Code | 8708.30.5030 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 4.528 IN |
| Mounting Bolt Hole Circle Diameter | 115 MM |
| Mounting Bolt Hole Diameter | 0.495 IN |
| Mounting Bolt Hole Diameter | 12.55 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.145 IN |
| Nominal Thickness | 29.1 MM |
| Outside Diameter | 11.651 IN |
| Outside Diameter | 295.95 MM |
| Overall Height | 2.03 IN |
| Overall Height | 51.55 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352502617 |
RAYBESTOS 580547 Cross References
| Brand | Part Number |
|---|---|
| ASH85889, 829352502617 | |
| ADVANCE AUTO PARTS | YH145693, YH145693C, YH145693P |
| AUTOPARTSOURCE | 593875 |
| AUTOXTRA | AX900320 |
| AUTOZONE | 41229, 41229DG |
| BECK/ARNLEY | 083-3428 |
| BENDIX | PRT5693 |
| BOSCH | 25010685 |
| BRAKEBEST | 25010685, 580547, 580547FZN, 580547R, 580547RGS |
| Brembo | 09.A630.11 |
| CENTRIC | 120.66067, 121.66067, 126.66067CSL, 126.66067CSR, 126.66067SL, 126.66067SR, 127.66067CL, 127.66067CR, 127.66067L, 127.66067R, 128.66067L, 128.66067R, 320.66067, 321.66067 |
| Casting Numbers | 326363 |
| Centric Parts | 120.66067, 121.66067, 126.66067CSL, 126.66067CSR, 126.66067SL, 126.66067SR, 127.66067CL, 127.66067CR, 127.66067L, 127.66067R, 128.66067L, 128.66067R, 320.66067, 321.66067 |
| DURA CORP | BR55148, BR900320, BR90032002 |
| DuraGo | 60376, 900320, BR60376, BR900320, BR90032002 |
| Eurorotor | 55301 |
| GM | 15837488, 20892949, 20955857 |
| General Motors | 15837488, 20892949, 20955857 |
| MAGMA PRODUCTS | PSR225251 |
| MONROE BRAKES | BD126479 |
| NAPA BRAKES | SDK6586 |
| NEOTEK | 1072046GF |
| NEWTEK AUTOMOTIVE | 55148 |
| Newtek Automotive USA | 55148 |
| Omnicraft | QBRR190 |
| POWERSTOP | AR8667EVC |
| PROMAX | 14-55148, 20-55148 |
| PRONTO | BR900320 |
| QUALIS | 41229 |
| SATURN | 25804049 |
| SUZUKI | 5521178J00, 5521178J01 |
| TopNotch | TN580547GEO |
| UAP | 55148 |
| Ultra Brake | 55301 |
| WABCO | PS126479 |
| WABCO - Archived | PS126479 |
| WAGNER | BD126479, BD126479E |
| WAGNER BRAKE | BD126479, BD126479E |
| WINHERE | 6620717 |
| WORLDPAC | 1407-75134, 1427-731938 |
RAYBESTOS 580547 Fits Vehicles
- Chevrolet Captiva Sport (2008-2015)
- Saturn Vue (2008-2010)
- Pontiac Torrent (2007-2009)
- Suzuki XL-7 (2007-2009)
- Chevrolet Equinox (2007-2009)
