(888) 312-8812 Login SignupRAYBESTOS 980011 Raybestos Specialty - Street Performance Brake Rotor
$10449
Limited availability at this price!
1 Day Lead Time
Get it by Monday, Aug 17
RAYBESTOS 980011 Part Description
Manufacturer
Product Description
Raybestos Specialty - Street Performance Brake Rotor
Application Summary
2005-2001 BMW 325i Front, 2008-2003 BMW Z4 Front, 2006-2001 BMW 325Ci Front, 2005-2001 BMW 325xi Front, 2002-2001 BMW Z3 Front, 2000 BMW 323i Front, 2000-1999 BMW 328i Front, 2000 BMW 323Ci Front, 2000 BMW 328Ci Front
Features & Benefits
- Application Specific Enhanced Iron
- Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Cooling Vanes
- The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
- Application Specific Coating
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
- Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
- Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
- Turned Finish
- Turned finish minimizes noise and improves responsiveness for smoother stops.
- S-Groove Slot
- Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
- Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.
RAYBESTOS 980011 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 3.12 IN |
| Center Hole Diameter | 79.25 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 0.803 IN |
| Discard Thickness | 20.4 MM |
| Harmonize Code | 8708.30.5030 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 4.72 IN |
| Mounting Bolt Hole Circle Diameter | 119.9 MM |
| Mounting Bolt Hole Diameter | 0.573 IN |
| Mounting Bolt Hole Diameter | 14.55 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.86 IN |
| Nominal Thickness | 21.85 MM |
| Outside Diameter | 11.81 IN |
| Outside Diameter | 299.95 MM |
| Overall Height | 2.027 IN |
| Overall Height | 51.5 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00747730845494 |
RAYBESTOS 980011 Cross References
| Brand | Part Number |
|---|---|
| 747730845494, 120.34048 | |
| ADVANCE AUTO PARTS | N1000419559ZXC, YH145469, YH145469C, YH145469P |
| ALTROM IMPORTS | 34111164539 |
| ATE BRAKE PRODUCTS | 422160, SP22160 |
| AUTOSPECIALTY | EBR630, EBR630E |
| AUTOXTRA | AX34173 |
| AUTOZONE | 34173, 34173DG, 34173DL, DL34173 |
| BECK/ARNLEY | 083-2862 |
| BENDIX | 145469 |
| BMW | 34111164539, 34116757526, 34116766224, 34116864058 |
| BRAKEBEST | 15010055, 980011, 980011FZN, 980011R, 980011RGS, BD126233 |
| BREMBO | 09.7701.10, 25514 |
| Brembo | 09.7701.1X, 09.7701.11 |
| CENTRIC | 120.34048, 121.34048, 125.34048, 125.34048CRY, 126.34048CSL, 126.34048CSR, 126.34048SL, 126.34048SR, 127.34048L, 127.34048R, 128.34048CL, 128.34048CR, 128.34048L, 128.34048R, 227.34048L, 227.34048R, 320.34048, 320.34048F, 321.34048 |
| CONTINENTAL-CONTITECH | CW22160 |
| Casting Numbers | 211369-C, 325959 |
| Centric Parts | 120.34048, 121.34048, 125.34048, 125.34048CRY, 126.34048CSL, 126.34048CSR, 126.34048SL, 126.34048SR, 127.34048L, 127.34048R, 128.34048CL, 128.34048CR, 128.34048L, 128.34048R, 227.34048L, 227.34048R, 320.34048, 320.34048F, 321.34048 |
| DURA CORP | BR34173, BR3417302 |
| DuraGo | BR34173 |
| MAGMA PRODUCTS | PSR123049 |
| MIGHTY DISTRIBUTING SYSTEM | 34173 |
| MONROE BRAKES | BD126233 |
| NAPA BRAKES | SDK6103 |
| NEOTEK | 106664GF |
| NEWTEK AUTOMOTIVE | 34173 |
| Newtek Automotive USA | 34173 |
| Omnicraft | QBRR558 |
| PAGID | 355106552 |
| PAGID Racing | 355106552 |
| POWERSTOP | EBR630EVC |
| PROMAX | 14-34173 |
| PRONTO | BR34173 |
| QUALIS | 34173 |
| QUALITY BRAND | 34173, Q606 |
| QUINTON HAZELL | BDC5146 |
| STANDARD ROTORS AND DRUMS | GP34173 |
| TRUSTAR | 412540 |
| TRW | 4055, DF4055S |
| UAP | 34173 |
| Ultra Brake | BM-744 |
| VAICO | V2080043 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X51449 |
| WABCO | PS126233 |
| WABCO - Archived | PS126233 |
| WAGNER | BD180069, BD126233 |
| WAGNER BRAKE | BD126233 |
| WINHERE | 662999 |
| WORLDPAC | 1407-78451, 1427-731985 |
| Wagner Brake | BD126233E |
RAYBESTOS 980011 Fits Vehicles
- BMW 320i (2001-2005)
- BMW Z4 (2003-2008)
- BMW Z3 (2001-2002)
- BMW 328i (1999-2000)
- BMW 328Ci (2000)
- BMW 325xi (2001-2005)
- BMW 325i (2001-2005)
- BMW 325Ci (2001-2006)
- BMW 323i (1999-2001)
- BMW 323Ci (2000)
