(888) 312-8812 Login SignupRAYBESTOS 980141 Raybestos Specialty - Street Performance Brake Rotor
$57.19
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
RAYBESTOS 980141 Part Description
Manufacturer
Product Description
Raybestos Specialty - Street Performance Brake Rotor
Application Summary
2008-2003 Subaru Forester Front, 2005-2001 Subaru Outback Front, 2007-2002 Subaru Impreza Front, 2005-2000 Subaru Legacy Front, 2006-2003 Subaru Baja Front, 2006-2005 Saab 9-2X Front
Features & Benefits
- Application Specific Enhanced Iron
- Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Cooling Vanes
- The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
- Application Specific Coating
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
- Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
- Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
- Turned Finish
- Turned finish minimizes noise and improves responsiveness for smoother stops.
- S-Groove Slot
- Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
- Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.
RAYBESTOS 980141 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.29 IN |
| Center Hole Diameter | 58.15 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 0.866 IN |
| Discard Thickness | 22 MM |
| Harmonize Code | 8708.30.5030 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 3.93 IN |
| Mounting Bolt Hole Circle Diameter | 99.8 MM |
| Mounting Bolt Hole Diameter | 0.495 IN |
| Mounting Bolt Hole Diameter | 12.55 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.945 IN |
| Nominal Thickness | 24 MM |
| Outside Diameter | 11.545 IN |
| Outside Diameter | 293.25 MM |
| Overall Height | 2.23 IN |
| Overall Height | 56.65 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00753497986820 |
RAYBESTOS 980141 Cross References
| Brand | Part Number |
|---|---|
| 77830045, 753497986820 | |
| ADVANCE AUTO PARTS | 145406, YH145406, YH145406C, YH145406P |
| AUTOPARTSOURCE | 577250 |
| AUTOSPECIALTY | JBR957 |
| AUTOXTRA | 126174, AX34203 |
| AUTOZONE | 34203, 34203DG |
| BECK/ARNLEY | 083-2961 |
| BENDIX | 145406 |
| BRAKEBEST | 48011210, 81-126174, 980141, 980141FZN, 980141PER, 980141R, 980141RGS, BD126174 |
| BREMBO | 09.9077.10, 25646, 09.9077.1X, 09.9077.11 |
| CENTRIC | 120.47018, 120.47018CRY, 121.47018, 125.47018, 125.47018CRY, 126.47018CSL, 126.47018CSR, 126.47018SL, 126.47018SR, 127.47018CL, 127.47018CR, 127.47018L, 127.47018R, 128.47018CL, 128.47018CR, 128.47018L, 128.47018R, 227.47018L, 227.47018R, 320.47018, 321.47018 |
| CONTINENTAL-CONTITECH | CW21700 |
| Casting Numbers | 0572, 211464-C, 325569 |
| Centric Parts | 120.47018, 120.47018CRY, 121.47018, 125.47018, 125.47018CRY, 126.47018CSL, 126.47018CSR, 126.47018SL, 126.47018SR, 127.47018CL, 127.47018CR, 127.47018L, 127.47018R, 128.47018CL, 128.47018CR, 128.47018L, 128.47018R, 227.47018L, 227.47018R, 320.47018, 321.47018 |
| DURA CORP | BR34203, BR3420302 |
| DuraGo | BR34203, BR3420302 |
| GREN | 62802 |
| GUARDIAN | 52-126174 |
| MAGMA PRODUCTS | PSR525028 |
| MIGHTY DISTRIBUTING SYSTEM | 34203 |
| MONROE BRAKES | BD126174 |
| NAPA BRAKES | SDK6332, TSR650 |
| NEOTEK | 106415GF |
| NEWTEK AUTOMOTIVE | 34203 |
| Newtek Automotive USA | 34203 |
| Omnicraft | QBRR129 |
| POWERSTOP | JBR957EVC |
| PROMAX | 14-34203 |
| PRONTO | BR34203 |
| QUALIS | 34203 |
| QUALITEE INTERNATIONAL | 64-77-250 |
| QUALITY BRAND | Q541 |
| QUINTON HAZELL | BDC5165 |
| SAAB | 32006171 |
| STANDARD ROTORS AND DRUMS | 34203 |
| SUBARU | 26300AE061, 26300AE02A, 26300AE02B, 26300AE02C, 26300AE060, 26310AC040, 26310AC041 |
| TRUSTAR | 477250, R77250 |
| TRW | DF4104S |
| TopNotch | TN980141GEO |
| UAP | 2034203, 34203 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X51518 |
| WABCO | PS126174 |
| WABCO - Archived | PS126174 |
| WAGNER | BD126174, BD126174E |
| WAGNER BRAKE | BD126174, BD126174E |
| WINHERE | 662828 |
| WORLDPAC | 1407-78968, 1427-499369 |
RAYBESTOS 980141 Fits Vehicles
- Saab 9-2X (2005-2006)
- Subaru Outback (2001-2005)
- Subaru Legacy (2000-2005)
- Subaru Impreza (2002-2008)
- Subaru Forester (2003-2008)
- Subaru Baja (2003-2006)
