(888) 312-8812 Login SignupRAYBESTOS 980103 Raybestos Specialty - Street Performance Brake Rotor
$82.90
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
RAYBESTOS 980103 Part Description
Manufacturer
Product Description
Raybestos Specialty - Street Performance Brake Rotor
Application Summary
2005-2002 Audi A4 Quattro Rear, 2005-2002 Audi A4 Rear
Features & Benefits
- Application Specific Enhanced Iron
- Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Cooling Vanes
- The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
- Application Specific Coating
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
- Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
- Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
- Turned Finish
- Turned finish minimizes noise and improves responsiveness for smoother stops.
- S-Groove Slot
- Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
- Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.
RAYBESTOS 980103 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.677 IN |
| Center Hole Diameter | 68 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 0.394 IN |
| Discard Thickness | 10 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 4.409 IN |
| Mounting Bolt Hole Circle Diameter | 112 MM |
| Mounting Bolt Hole Diameter | 0.605 IN |
| Mounting Bolt Hole Diameter | 15.35 MM |
| Mounting Bolt Hole Quantity | 10 |
| Nominal Thickness | 0.469 IN |
| Nominal Thickness | 11.9 MM |
| Outside Diameter | 10.039 IN |
| Outside Diameter | 255 MM |
| Overall Height | 1.567 IN |
| Overall Height | 39.8 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 10 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | IT |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352044421 |
RAYBESTOS 980103 Cross References
| Brand | Part Number |
|---|---|
| 829352044421, 120.33108 | |
| ADVANCE AUTO PARTS | YH145434, YH145434C |
| ATE BRAKE PRODUCTS | SP12148, 412148 |
| AUDI | 8E0615601D |
| AUTOXTRA | AX34217 |
| AUTOZONE | 34217, 34217DG |
| BENDIX | 145434 |
| BRAKEBEST | 980103, 980103R, 980103RGS |
| BREMBO | 08.9918.21, 25709 |
| BrakeBest | 980430RGS |
| CENTRIC | 120.33070, 120.33108, 121.33106, 121.33108, 125.33106, 125.33106CRY, 125.33108, 125.33108CRY, 126.33106CSL, 126.33106CSR, 126.33106SL, 126.33106SR, 126.33108CSL, 126.33108CSR, 126.33108SL, 126.33108SR, 127.33106CL, 127.33106CR, 127.33106L, 127.33106R, 127.33108CL, 127.33108CR, 127.33108L, 127.33108R, 128.33108L, 128.33108R, 128.33106CL, 128.33106CR, 128.33106L, 128.33106R, 128.33108CL, 128.33108CR, 320.33106C, 320.33108C |
| Casting Numbers | 325982, 8E0615601D |
| Centric Parts | 120.33070, 120.33108, 121.33106, 121.33108, 125.33106, 125.33106CRY, 125.33108, 125.33108CRY, 126.33106CSL, 126.33106CSR, 126.33106SL, 126.33106SR, 126.33108CSL, 126.33108CSR, 126.33108SL, 126.33108SR, 127.33106CL, 127.33106CR, 127.33106L, 127.33106R, 127.33108CL, 127.33108CR, 127.33108L, 127.33108R, 128.33106CL, 128.33106CR, 128.33106L, 128.33106R, 128.33108CL, 128.33108CR, 128.33108L, 128.33108R, 320.33106C, 320.33108C |
| DURA CORP | BR34217 |
| DuraGo | BR34217 |
| MAGMA PRODUCTS | PSR583055 |
| MIGHTY DISTRIBUTING SYSTEM | 34217 |
| NEWTEK AUTOMOTIVE | 34217 |
| Newtek Automotive USA | 34217 |
| PAGID | 355107562 |
| PAGID Racing | 355107562 |
| PEP BOYS | 34217G |
| PILENGA | 5876 |
| POWERSTOP | EBR656EVC |
| PROMAX | 14-34217 |
| PRONTO | BR34217 |
| QUALIS | 34217 |
| Qualis | 45429 |
| UAP | 34217 |
| VAICO | V1040074 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X51620 |
| WINHERE | 661548 |
| WORLDPAC | 1427-499361 |
| Wagner Brake | BD126450E |
RAYBESTOS 980103 Fits Vehicles
- Audi A4 Quattro (2002-2005)
- Audi A4 (2002-2005)
RAYBESTOS 980103 Customer Reviews
No reviews yet
Be the first to review this product!
RAYBESTOS 980103 Questions & Answers
No questions yet
Be the first to ask a question about this product!
