(888) 312-8812 Login SignupRAYBESTOS 76447 Raybestos Specialty - Truck Brake Rotor
$9199
Limited availability at this price!
In Stock
Get it by Friday, Jul 10
RAYBESTOS 76447 Part Description
Manufacturer
Product Description
Raybestos Specialty - Truck Brake Rotor
Application Summary
1999-1994 Dodge Ram 1500 Front
Features & Benefits
- OE Fit, Form, and Function
- Our vehicle-specific design matches OE fit, form and function, providing ultimate strength and performance
- Cooling Vanes
- We dedicate time to match the cooling vanes on our Specialty rotors to OE designs, ensuring: Optimal cooling Reduced fade Less noise Increased pad life
- Coating
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0® rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0(R) rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- SAE Standard for Tensile Strength
- Our rotors follow SAE standards for tensile strength, hardness, and iron grade, providing structural integrity and maximum service life
- Turned Finish
- A turned finish provides an excellent surface for the pads to engage with to ensure a smooth and effective stop right out of the box
RAYBESTOS 76447 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 3.09 IN |
| Center Hole Diameter | 78.5 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 1.215 IN |
| Discard Thickness | 30.85 MM |
| Harmonize Code | 8708.30.5030 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 5.5 IN |
| Mounting Bolt Hole Circle Diameter | 139.7 MM |
| Mounting Bolt Hole Diameter | 0.62 IN |
| Mounting Bolt Hole Diameter | 15.75 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.285 IN |
| Nominal Thickness | 32.65 MM |
| Outside Diameter | 11.61 IN |
| Outside Diameter | 294.9 MM |
| Overall Height | 2.575 IN |
| Overall Height | 65.4 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00030999746566 |
RAYBESTOS 76447 Cross References
| Brand | Part Number |
|---|---|
| 25121606, 30999746566 | |
| ADVANCE AUTO PARTS | 141940, YH141940, YH141940C, YH141940P |
| AMERICAN REMANUFACTURED | 789-40029, 89-40029 |
| AUTOPART INTERNATIONAL | 25571 |
| AUTOPARTSOURCE | 491630 |
| AUTOSPECIALTY | AR8729, AR8729E |
| AUTOZONE | 5365, 5365B, 5365DG, DL5365 |
| BENDIX | 141940, R449889 |
| BOSCH | 16010156, RBR5365 |
| BRAKE HEADQUARTERS | BR53332 |
| BRAKE PRO | 4615365 |
| BRAKEBEST | 16010156, 76447, 76447FZN, 76447PER, 76447R, 76447RGS, 81-125388, BD125388 |
| BREMBO | 09.8181.80, 27083 |
| CALIFORNIA DRUM & ROTOR | 125388 |
| CENTRIC | 120.67029, 121.67029, 125.67029, 126.67029CSL, 126.67029CSR, 126.67029SL, 126.67029SR, 127.67029CL, 127.67029CR, 127.67029L, 127.67029R, 227.67029L, 227.67029R, 320.67029, 320.67029F |
| CENTURY | 7059 |
| CHRYSLER | 52008219 |
| CONTINENTAL-CONTITECH | CW33700 |
| Casting Numbers | 210624-C, 325176, 53651 |
| Centric Parts | 120.67029, 121.67029, 125.67029, 126.67029CSL, 126.67029CSR, 126.67029SL, 126.67029SR, 127.67029CL, 127.67029CR, 127.67029L, 127.67029R, 227.67029L, 227.67029R, 320.67029, 320.67029F |
| DELPHI | RB593 |
| DURA CORP | BR5365 |
| DuraGo | BR5365 |
| EIS BRAKES | D17730 |
| EUCLID | E-9889 |
| EUROROTOR | 53151 |
| GREN | 614502 |
| GUARDIAN | 52-125388 |
| MAGMA PRODUCTS | PSR145133 |
| MERITOR | R449889 |
| MIDAS | BR1955 |
| MIGHTY DISTRIBUTING SYSTEM | 5365 |
| MONROE BRAKES | BD125388 |
| NEWTEK AUTOMOTIVE | 5365 |
| Newtek Automotive USA | 5365 |
| Omnicraft | QBRR44 |
| PARTS MASTER | P125388 |
| POWERSTOP | AR8729EVC |
| PROMAX | 14-5365 |
| PRONTO | BR5365 |
| QUALIS | 5365 |
| QUALITY BRAND | 5365 |
| STANDARD ROTORS AND DRUMS | 5365 |
| THE UNIVERSAL GROUP | 102103 |
| UAP | 5365 |
| Ultra Brake | 53151 |
| Universal | 102103 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X50868 |
| WABCO | PS125388 |
| WABCO - Archived | PS125388 |
| WAGNER | BD125388 |
| WAGNER BRAKE | BD125388 |
| WINHERE | 442171, YH2171 |
| WORLDPAC | 1407-25571 |
RAYBESTOS 76447 Fits Vehicles
- Chrysler Voyager (1995)
- Dodge Ram 1500 (1994-1999)
