(888) 312-8812 Login SignupRAYBESTOS 580438 Raybestos Specialty - Truck Brake Rotor
$113.40
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
RAYBESTOS 580438 Part Description
Manufacturer
Product Description
Raybestos Specialty - Truck Brake Rotor
Application Summary
1999-1988 Chevrolet K1500 Front, 2000-1995 Chevrolet Tahoe Front, 1999-1988 GMC K1500 Front, 1998-1988 Chevrolet K2500 Front, 1999-1992 Chevrolet K1500 Suburban Front, 2000-1992 GMC Yukon Front, 1998-1988 GMC K2500 Front
Features & Benefits
- OE Fit, Form, and Function
- Our vehicle-specific design matches OE fit, form and function, providing ultimate strength and performance
- Cooling Vanes
- We dedicate time to match the cooling vanes on our Specialty rotors to OE designs, ensuring: Optimal cooling Reduced fade Less noise Increased pad life
- Coating
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0® rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0(R) rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- SAE Standard for Tensile Strength
- Our rotors follow SAE standards for tensile strength, hardness, and iron grade, providing structural integrity and maximum service life
- Turned Finish
- A turned finish provides an excellent surface for the pads to engage with to ensure a smooth and effective stop right out of the box
RAYBESTOS 580438 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 3.098 IN |
| Center Hole Diameter | 78.7 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 1.215 IN |
| Discard Thickness | 30.85 MM |
| Harmonize Code | 8708.30.5030 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 5.5 IN |
| Mounting Bolt Hole Circle Diameter | 139.7 MM |
| Mounting Bolt Hole Diameter | 0.605 IN |
| Mounting Bolt Hole Diameter | 15.35 MM |
| Mounting Bolt Hole Quantity | 6 |
| Nominal Thickness | 1.285 IN |
| Nominal Thickness | 32.65 MM |
| Outside Diameter | 11.61 IN |
| Outside Diameter | 294.9 MM |
| Overall Height | 2.6 IN |
| Overall Height | 66.05 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 6 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352448977 |
RAYBESTOS 580438 Cross References
| Brand | Part Number |
|---|---|
| 94140960, 829352448977 | |
| ACDELCO | 177-716 |
| ADVANCE AUTO PARTS | N1000125111APO, YH141453, YH141453C, YH141453P |
| AUTOPARTSOURCE | 493940 |
| AUTOXTRA | 61812, AX5569 |
| AUTOZONE | 5569DG, DL55135 |
| AutoZone | 55051DL, 5569 |
| BRAKEBEST | 25010536, 580438, 580438FZN, 580438PER, 580438R, 580438RGS |
| BREMBO | 09.7815.11 |
| Bridgestone | 7096830 |
| CENTRIC | 120.66009, 120.66009CRY, 121.66009, 125.66009, 125.66009CRY, 126.66009CSL, 126.66009CSR, 126.66009SL, 126.66009SR, 127.66009CL, 127.66009CR, 127.66009L, 127.66009R, 128.66009CL, 128.66009CR, 128.66009L, 128.66009R, 227.66009L, 227.66009R, 320.66009, 320.66009F, 321.66009 |
| Centric Parts | 120.66009, 120.66009CRY, 121.66009, 125.66009, 125.66009CRY, 126.66009CSL, 126.66009CSR, 126.66009SL, 126.66009SR, 127.66009CL, 127.66009CR, 127.66009L, 127.66009R, 128.66009CL, 128.66009CR, 128.66009L, 128.66009R, 227.66009L, 227.66009R, 320.66009, 320.66009F, 321.66009 |
| DURA CORP | BR55135, BR556902 |
| DuraGo | BR5569 |
| GM | 15521902, 15679710, 18027858, 18028089 |
| GUARDIAN | 52-61812 |
| General Motors | 15521902, 15679710, 18027858, 18028089 |
| MAGMA PRODUCTS | PSR225178 |
| MONROE BRAKES | BD61812 |
| NEOTEK | 107238GF |
| NEWTEK AUTOMOTIVE | 55135 |
| Newtek Automotive USA | 55135 |
| Omnicraft | QBRR194 |
| PRONTO | BR5569 |
| Parts Master | 61812 |
| QUALIS | 1015569 |
| QUALITY BRAND | 5569C |
| Qualis | 5569 |
| TopNotch | TN580438GEO |
| WAGNER | BD61812E, BD61812 |
| WORLDPAC | 1407-25062 |
| Wagner Brake | BD61812E |
RAYBESTOS 580438 Fits Vehicles
- GMC Yukon (1992-2000)
- GMC K2500 Suburban (1992-1997)
- GMC K2500 (1988-1998)
- GMC K1500 Suburban (1992-1999)
- GMC K1500 (1988-1999)
- Chevrolet Tahoe (1995-2000)
- Chevrolet K2500 Suburban (1992-1997)
- Chevrolet K2500 (1988-1998)
- Chevrolet K1500 Suburban (1992-1999)
- Chevrolet K1500 (1988-1999)
- Chevrolet Blazer (1992-1994)
- Cadillac Escalade (1999-2000)
