RAYBESTOS 580401 Part Description
Manufacturer
Product Description
Raybestos Specialty - Street Performance Brake Rotor
Application Summary
2010-2006 Chevrolet Impala Rear, 2009-2008 Buick LaCrosse Rear, 2007-2006 Chevrolet Monte Carlo Rear, 2009-2008 Buick Allure Rear
Features & Benefits
- Application Specific Enhanced Iron
- Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Cooling Vanes
- The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
- Application Specific Coating
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
- Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
- Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
- Turned Finish
- Turned finish minimizes noise and improves responsiveness for smoother stops.
- S-Groove Slot
- Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
- Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.
RAYBESTOS 580401 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.783 IN |
| Center Hole Diameter | 70.7 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 0.35 IN |
| Discard Thickness | 8.9 MM |
| Harmonize Code | 8708.30.5030 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 4.53 IN |
| Mounting Bolt Hole Circle Diameter | 115.05 MM |
| Mounting Bolt Hole Diameter | 0.557 IN |
| Mounting Bolt Hole Diameter | 14.15 MM |
| Nominal Thickness | 0.43 IN |
| Nominal Thickness | 10.9 MM |
| Outside Diameter | 10.945 IN |
| Outside Diameter | 278 MM |
| Overall Height | 1.996 IN |
| Overall Height | 50.7 MM |
| Salability Restrictions | No |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352361337 |
RAYBESTOS 580401 Cross References
| Brand | Part Number |
|---|---|
| 85550110, 829352361337 | |
| ACDELCO | 177-908 |
| ADVANCE AUTO PARTS | G12545SD, YH145628, YH145628C, YH145628P |
| AUTOPARTSOURCE | 593745 |
| AUTOXTRA | AX55125, AX900650 |
| AUTOZONE | 55125, 55125DG, 55125DL, 55125SD |
| Autoxtra | AX55125P |
| BENDIX | 145628 |
| BOSCH | 25010644 |
| BRAKEBEST | 25010644, 580401FZN, 580401P, 580401, 580401PER, 580401R, 580401RGS |
| CENTRIC | 120.62097, 120.62097CRY, 121.62097, 126.62097CSL, 126.62097CSR, 126.62097SL, 126.62097SR, 127.62097R, 127.62097CR, 127.62097L, 128.62097CL, 128.62097CR, 128.62097L, 128.62097R, 320.62097, 321.62097 |
| Casting Numbers | 210736-C, 326248 |
| Centric Parts | 120.62097, 120.62097CRY, 121.62097, 126.62097CSL, 126.62097CSR, 126.62097SL, 126.62097SR, 127.62097CR, 127.62097L, 127.62097R, 128.62097CL, 128.62097CR, 128.62097L, 128.62097R, 320.62097, 321.62097 |
| DURA CORP | BR55125, BR5512502, BR900650 |
| DuraGo | 900650, BR55125, BR5512502, BR900650 |
| GM | 25956847, 88965647 |
| General Motors | 25956847, 88965647 |
| MAGMA PRODUCTS | PSR223106 |
| MONROE BRAKES | BD126348 |
| NEOTEK | 1072038GF |
| NEWTEK AUTOMOTIVE | 55125 |
| Newtek Automotive USA | 55125 |
| Omnicraft | QBRR142 |
| POWERSTOP | AR82111EVC |
| PROMAX | 14-55125, 20-55125 |
| PRONTO | BR55125 |
| PowerStop | PSR661708 |
| QUALIS | 55125 |
| QUALITY BRAND | Q4235 |
| TopNotch | TN580401GEO |
| UAP | 55125 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X51729 |
| WABCO | PS126348 |
| WABCO - Archived | PS126348 |
| WAGNER | BD126348E, BD126348 |
| WAGNER BRAKE | BD126348, BD126348E |
| WINHERE | 661708 |
| WORLDPAC | 1407-80288 |
RAYBESTOS 580401 Fits Vehicles
- Buick Allure (2008-2009)
- Buick LaCrosse (2008-2009)
- Chevrolet Monte Carlo (2006-2007)
- Chevrolet Impala (2006-2010)
