(888) 312-8812 Login SignupRAYBESTOS 6048 Raybestos Specialty - Truck Brake Rotor
$73.64
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
RAYBESTOS 6048 Part Description
Manufacturer
Product Description
Raybestos Specialty - Truck Brake Rotor
Application Summary
1993-1976 Ford F-150 Front, 1993-1976 Ford Bronco Front, 1976-1975 Ford F-100 Front
Features & Benefits
- OE Fit, Form, and Function
- Our vehicle-specific design matches OE fit, form and function, providing ultimate strength and performance
- Cooling Vanes
- We dedicate time to match the cooling vanes on our Specialty rotors to OE designs, ensuring: Optimal cooling Reduced fade Less noise Increased pad life
- Coating
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0® rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0(R) rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- SAE Standard for Tensile Strength
- Our rotors follow SAE standards for tensile strength, hardness, and iron grade, providing structural integrity and maximum service life
- Turned Finish
- A turned finish provides an excellent surface for the pads to engage with to ensure a smooth and effective stop right out of the box
RAYBESTOS 6048 Specifications
Product Attributes
| Center Hole Diameter | 3.88 IN |
| Center Hole Diameter | 98.55 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 1.12 IN |
| Discard Thickness | 28.45 MM |
| Harmonize Code | 8708.30.5030 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 5.5 IN |
| Mounting Bolt Hole Circle Diameter | 139.7 MM |
| Mounting Bolt Hole Diameter | 0.645 IN |
| Mounting Bolt Hole Diameter | 16.4 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.185 IN |
| Nominal Thickness | 30.1 MM |
| Outside Diameter | 11.72 IN |
| Outside Diameter | 297.7 MM |
| Overall Height | 2.704 IN |
| Overall Height | 68.7 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00030999096425 |
RAYBESTOS 6048 Cross References
| Brand | Part Number |
|---|---|
| 140-1850, 30999096425 | |
| ACDELCO | 177-590, 177-627 |
| ADVANCE AUTO PARTS | 141214, YH141214 |
| AMERICAN REMANUFACTURED | 789-42013, 89-42013 |
| AUTOPART INTERNATIONAL | 25043 |
| AUTOSPECIALTY | AR8513, AR8513E |
| AUTOXTRA | 60441, 806048 |
| AUTOZONE | 5446, 5446B, DL5446 |
| BENDIX | 141214, R449248 |
| BOSCH | 20010425, RBR5446 |
| BRAKE HEADQUARTERS | BR54460 |
| BRAKE PRO | 4616048 |
| BRAKEBEST | 20010425, 6048, 6048R, 6048RGS, 81-60441, BD60441 |
| BREMBO | 09.7438.80, 27022 |
| Bridgestone | 7015571 |
| CALIFORNIA DRUM & ROTOR | 60441 |
| CENTRIC | 120.65013, 121.65013, 125.65013, 126.65013CSL, 126.65013CSR, 126.65013SL, 126.65013SR, 127.65013CL, 127.65013CR, 127.65013L, 127.65013R, 128.65013CL, 128.65013CR, 128.65013L, 128.65013R, 227.65013L, 227.65013R, 320.65013F, 12165013 |
| CENTURY | 6048 |
| CERTIFIED DIVISION | HR93 |
| CONTINENTAL-CONTITECH | CW30712 |
| Casting Numbers | 211501-DP, 325235, 4553, 54461, 636048 |
| Centric Parts | 120.65013, 121.65013, 125.65013, 126.65013CSL, 126.65013CSR, 126.65013SL, 126.65013SR, 127.65013CL, 127.65013CR, 127.65013L, 127.65013R, 128.65013CL, 128.65013CR, 128.65013L, 128.65013R, 227.65013L, 227.65013R, 320.65013F |
| DAYTON WALTHER | D4612, D4633, D4736 |
| DELPHI | RB595 |
| DURA CORP | BR5446 |
| DuraGo | BR5446 |
| EIS BRAKES | D6048 |
| EUCLID | E-9248 |
| EUROROTOR | 5446 |
| FADE FREE | 60441 |
| FORD | D6TZ1102A, E1TZ1102A, E7TZ1102A, E8TZ1125D, F3TZ1102A, F3TZ1102AA, YL3Z1V125BB |
| GREN | 633802 |
| GUARDIAN | 52-60441 |
| GUNITE | G14633 |
| KELSEY HAYES | 14633, 14612 |
| MAGMA PRODUCTS | PSR205115 |
| MAREMONT | 7936048 |
| MCI | 5056 |
| MERITOR | R449248 |
| MIDAS | BR1054 |
| MIDLAND | 85611 |
| MIGHTY DISTRIBUTING SYSTEM | 5446 |
| MONROE BRAKES | BD60441 |
| MOPAR | 3-1432 |
| MOTORCRAFT | BRR8 |
| NEWTEK AUTOMOTIVE | 5446 |
| Newtek Automotive USA | 5446 |
| PARTS MASTER | P60441 |
| PRAEFKE | 141214 |
| PROMAX | 14-5446 |
| PRONTO | BR5446 |
| QUALIS | 5446 |
| QUALITEE INTERNATIONAL | 64-92-610 |
| QUALITY BRAND | 5446 |
| ROADMATES | 526025 |
| ROCKHILL | 5492 |
| SEARS | 1776, 510444 |
| STANDARD ROTORS AND DRUMS | 5446 |
| THE UNIVERSAL GROUP | 102460 |
| TRUSTAR | 492610, R92610 |
| UAP | 5446 |
| Universal | 102460 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X50270 |
| WAGNER | BD60441 |
| WAGNER BRAKE | BD60441 |
| WINHERE | 442328, YH2328 |
| WORLDPAC | 1427-719618 |
RAYBESTOS 6048 Fits Vehicles
- Ford F-150 (1976-1993)
- Ford F-100 (1975-1976)
- Ford Bronco (1976-1993)
