(888) 312-8812 Login SignupRAYBESTOS 580137 Raybestos Specialty - Street Performance Brake Rotor
$6999
Limited availability at this price!
1 Day Lead Time
Get it by Friday, Aug 14
RAYBESTOS 580137 Part Description
Manufacturer
Product Description
Raybestos Specialty - Street Performance Brake Rotor
Application Summary
2007-2005 Chevrolet Cobalt Front, 2007-2003 Saturn Ion Front, 2007 Pontiac G5 Front, 2006-2005 Pontiac Pursuit Front, 2006-2005 Pontiac G4 Front
Features & Benefits
- Application Specific Enhanced Iron
- Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Cooling Vanes
- The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
- Application Specific Coating
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
- Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
- Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
- Turned Finish
- Turned finish minimizes noise and improves responsiveness for smoother stops.
- S-Groove Slot
- Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
- Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.
RAYBESTOS 580137 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.37 IN |
| Center Hole Diameter | 60.2 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 0.866 IN |
| Discard Thickness | 22 MM |
| Harmonize Code | 8708.30.5030 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 3.93 IN |
| Mounting Bolt Hole Circle Diameter | 99.8 MM |
| Mounting Bolt Hole Diameter | 0.546 IN |
| Mounting Bolt Hole Diameter | 13.85 MM |
| Mounting Bolt Hole Quantity | 4 |
| Nominal Thickness | 0.945 IN |
| Nominal Thickness | 24 MM |
| Outside Diameter | 10.08 IN |
| Outside Diameter | 256.05 MM |
| Overall Height | 1.84 IN |
| Overall Height | 46.75 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 4 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352175545 |
RAYBESTOS 580137 Cross References
| Brand | Part Number |
|---|---|
| ADVANCE AUTO PARTS | 145419, YH145419, YH145419C, YH145419P |
| AUTOPARTSOURCE | 593335 |
| AUTOXTRA | 80580137, AX55083 |
| AUTOZONE | 55083, 55083DG, 55083DL, DL55083 |
| BENDIX | 145419 |
| BOSCH | 25010570 |
| BRAKEBEST | 25010570, 580137, 580137FZN, 580137R, 580137RGS, 81-126100, BD126100 |
| BREMBO | 09.B606.10, 27326 |
| Brembo | 09.B606.11 |
| CENTRIC | 120.62072, 120.62072CRY, 121.62072, 126.62072CSL, 126.62072CSR, 126.62072SL, 126.62072SR, 127.62072CL, 127.62072CR, 127.62072L, 127.62072R, 128.62072CL, 128.62072CR, 128.62072L, 128.62072R, 227.62072L, 227.62072R, 320.62072 |
| Casting Numbers | 211474-C, 325611 |
| Centric Parts | 120.62072, 120.62072CRY, 121.62072, 126.62072CSL, 126.62072CSR, 126.62072SL, 126.62072SR, 127.62072CL, 127.62072CR, 127.62072L, 127.62072R, 128.62072CL, 128.62072CR, 128.62072L, 128.62072R, 227.62072L, 227.62072R, 320.62072 |
| DURA CORP | BR55083, BR5508302 |
| DuraGo | 900646, BR55083, BR5508302, BR900646 |
| GREN | 486102 |
| GUARDIAN | 52-126100 |
| MAGMA PRODUCTS | PSR223079 |
| MIGHTY DISTRIBUTING SYSTEM | 55083 |
| MONROE BRAKES | BD126100 |
| NEOTEK | 107289GF |
| NEWTEK AUTOMOTIVE | 55083 |
| Newtek Automotive USA | 55083 |
| Omnicraft | QBRR217 |
| POWERSTOP | AR8288EVC |
| PROMAX | 14-55083, 20-55083 |
| PRONTO | BR55083 |
| QUALIS | 55083 |
| QUALITEE INTERNATIONAL | 64-93-335 |
| QUALITY BRAND | Q4172 |
| Qualis | 41250 |
| SATURN | 22702612 |
| TRUSTAR | 493335, R93335 |
| TopNotch | TN580137GEO |
| UAP | 55083 |
| Ultra Brake | 55170 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X51482 |
| WABCO | PS126100 |
| WABCO - Archived | PS126100 |
| WAGNER | BD126100, BD126100E |
| WAGNER BRAKE | BD126100, BD126100E |
| WINHERE | 662908 |
| WORLDPAC | 1407-77196 |
RAYBESTOS 580137 Fits Vehicles
- Pontiac G4 (2005-2006)
- Pontiac G5 (2007-2010)
- Pontiac Pursuit (2005-2006)
- Chevrolet Cobalt (2005-2010)
- Saturn Ion (2003-2007)
