RAYBESTOS 580722 Part Description
Manufacturer
Product Description
Raybestos Specialty - Street Performance Brake Rotor
Application Summary
2015-2010 Chevrolet Camaro Rear, 2014-2008 Cadillac CTS Rear
Features & Benefits
- Application Specific Enhanced Iron
- Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Cooling Vanes
- The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
- Application Specific Coating
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
- Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
- Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
- Turned Finish
- Turned finish minimizes noise and improves responsiveness for smoother stops.
- S-Groove Slot
- Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
- Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.
RAYBESTOS 580722 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Bearings Included | No |
| Center Hole Diameter | 2.65 IN |
| Center Hole Diameter | 67.3 MM |
| Construction | Full Cast |
| Conventional Or Drum-In-Hat Type Rotor | Drum-In-Hat |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 0.85 IN |
| Discard Thickness | 21.6 MM |
| Grade Type | Regular |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 9.177 IN |
| Inside Diameter | 233.1 MM |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 4.72 IN |
| Mounting Bolt Hole Circle Diameter | 119.9 MM |
| Mounting Bolt Hole Diameter | 0.645 IN |
| Mounting Bolt Hole Diameter | 16.4 MM |
| Nominal Thickness | 0.91 IN |
| Nominal Thickness | 23.1 MM |
| Outside Diameter | 12.4 IN |
| Outside Diameter | 314.95 MM |
| Overall Height | 1.89 IN |
| Overall Height | 48 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Diameter | 0.645 IN |
| Stud/Lug Hole Diameter | 16.4 MM |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352749043 |
RAYBESTOS 580722 Cross References
| Brand | Part Number |
|---|---|
| ADVANCE AUTO PARTS | N1000383435WBR, YH200476, YH200476C |
| AUTOPARTSOURCE | 493955 |
| AUTOXTRA | AX900506 |
| AUTOZONE | 57107, 57107DG |
| BENDIX | PRT5836 |
| BOSCH | 25011454 |
| BRAKEBEST | 25011454, 580722, 580722FZN, 580722R, 580722RGS |
| BREMBO | 09.N286.11 |
| BrakeBest | 521128RGS |
| CENTRIC | 120.62105, 120.62105CRY, 121.62105, 125.62124CRY, 126.62105SL, 126.62105SR, 127.62105CL, 127.62105CR, 127.62105L, 127.62105R, 128.62105CL, 128.62105CR, 128.62105L, 128.62105R, 320.62105 |
| Centric Parts | 125.62124CRY, 120.62105, 120.62105CRY, 121.62105, 126.62105SL, 126.62105SR, 127.62105CL, 127.62105CR, 127.62105L, 127.62105R, 128.62105CL, 128.62105CR, 128.62105L, 128.62105R, 320.62105 |
| DURA CORP | BR55171, BR900506, BR90050602 |
| DuraGo | 900506, BR900506, BR90050602 |
| GM | 13501315, 15267107, 20808621, 23132528 |
| General Motors | 13501315, 15267107, 20808621, 23132528, 13502959 |
| MAGMA PRODUCTS | PSR223120 |
| MONROE BRAKES | BD180183 |
| N/A | 120.62124, 121.62124, 125.62124, 126.62124CSL, 126.62124CSR, 126.62124SL, 126.62124SR, 127.62124CL, 127.62124CR, 127.62124L, 127.62124R, 128.62124CL, 128.62124CR, 128.62124L, 128.62124R, 227.62124L, 227.62124R, 320.62124, 320.62124C |
| NEOTEK | 1072023GF |
| NEWTEK AUTOMOTIVE | 55171 |
| Newtek Automotive USA | 55171 |
| POWERSTOP | AR82127EVC |
| PROMAX | 14-55171 |
| PRONTO | BR900506 |
| Qualis | 41237 |
| TopNotch | TN580722GEO |
| UAP | R62105 |
| WABCO | PS900506 |
| WABCO - Archived | PS900506 |
| WAGNER BRAKE | BD180183 |
| WINHERE | 6621270 |
| WORLDPAC | 1407-76037, 1427-719763 |
| Wagner Brake | BD180183E |
RAYBESTOS 580722 Fits Vehicles
- Chevrolet Camaro (2010-2015)
- Cadillac CTS (2008-2014)
