(888) 312-8812 Login SignupRAYBESTOS 66595 Raybestos Specialty - Street Performance Brake Rotor
$9599
Limited availability at this price!
In Stock
Get it by Friday, Aug 7
RAYBESTOS 66595 Part Description
Manufacturer
Product Description
Raybestos Specialty - Street Performance Brake Rotor
Application Summary
2002-1996 Mercury Grand Marquis Rear, 2002-1996 Ford Crown Victoria Rear, 2002-1996 Lincoln Town Car Rear, 2002-1996 Ford Grand Marquis Rear
Features & Benefits
- Application Specific Enhanced Iron
- Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Cooling Vanes
- The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
- Application Specific Coating
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
- Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
- Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
- Turned Finish
- Turned finish minimizes noise and improves responsiveness for smoother stops.
- S-Groove Slot
- Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
- Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.
RAYBESTOS 66595 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.78 IN |
| Center Hole Diameter | 70.6 MM |
| Conventional Or Drum-In-Hat Type Rotor | Drum-In-Hat |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 0.512 IN |
| Discard Thickness | 13 MM |
| Harmonize Code | 8708.30.5030 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 4.5 IN |
| Mounting Bolt Hole Circle Diameter | 114.3 MM |
| Mounting Bolt Hole Diameter | 0.557 IN |
| Mounting Bolt Hole Diameter | 14.15 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.55 IN |
| Nominal Thickness | 13.95 MM |
| Outside Diameter | 11.215 IN |
| Outside Diameter | 284.85 MM |
| Overall Height | 2.3 IN |
| Overall Height | 58.4 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Solid |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00030999967817 |
RAYBESTOS 66595 Cross References
| Brand | Part Number |
|---|---|
| 29546229, 30999967817 | |
| ADVANCE AUTO PARTS | 145109, YH145109 |
| AMERICAN REMANUFACTURED | 789-34052, 89-34052, 89-84009 |
| AUTOPART INTERNATIONAL | 25446 |
| AUTOSPECIALTY | AR8152, AR8152E |
| AUTOXTRA | 125481, 8066595, AX54027 |
| AUTOZONE | 54027, 54027B, DL54027 |
| BENDIX | 145109 |
| BOSCH | RBR54027 |
| BRAKE HEADQUARTERS | BR54554 |
| BRAKEBEST | 20010332, 66595, 66595R, 66595RGS, 81-125481, BD125481 |
| BREMBO | 08.8214.85, 27154 |
| BrakeBest | 66597RGS |
| Brembo | 08.8214.81 |
| Bridgestone | 7002436 |
| CALIFORNIA DRUM & ROTOR | 125481 |
| CENTRIC | 120.61052, 120.61052CRY, 121.61052, 125.61052, 125.61052CRY, 126.61052CSL, 126.61052CSR, 126.61052SL, 126.61052SR, 127.61052CL, 127.61052CR, 127.61052L, 127.61052R, 128.61052CL, 128.61052CR, 128.61052L, 128.61052R, 320.61052, 320.61052F, 321.61052 |
| COMMAND AUTOMOTIVE | 107111 |
| CONTINENTAL-CONTITECH | CW14701 |
| Casting Numbers | 210722-C, 325206, 540271 |
| Centric Parts | 120.61052, 120.61052CRY, 121.61052, 125.61052, 125.61052CRY, 126.61052CSL, 126.61052CSR, 126.61052SL, 126.61052SR, 127.61052CL, 127.61052CR, 127.61052L, 127.61052R, 128.61052CL, 128.61052CR, 128.61052L, 128.61052R, 320.61052, 320.61052F, 321.61052 |
| DELPHI | RB420 |
| DURA CORP | BR54027 |
| DuraGo | BR54027 |
| EIS BRAKES | D17821 |
| EUROROTOR | 54201 |
| FORD | F6AZ2C026A, F6AZ2C026AA, F6AZ2C026BA, F7AZ2C026AA, XW7Z2C026AA, YW7Z2C026AA |
| FORMULA BLUE HYDRAULIC BRAKE PARTS | E12566057 |
| GREN | 647501 |
| GUARDIAN | 52-125481 |
| MAGMA PRODUCTS | PSR203058 |
| MIDAS | BR1986 |
| MIGHTY DISTRIBUTING SYSTEM | 54027 |
| MONROE BRAKES | BD125481 |
| MOTORCRAFT | BRR61 |
| Motorcraft | NBRR100 |
| NEOTEK | 107111GF |
| NEWTEK AUTOMOTIVE | 54027 |
| Newtek Automotive USA | 54027 |
| PARTS MASTER | P125481 |
| PERFORMANCE FRICTION | 284.050.01 |
| POWERSTOP | AR8152EVC |
| PROMAX | 14-54027 |
| PRONTO | BR54027 |
| QUALIS | 54027 |
| QUALITEE INTERNATIONAL | 64-92-410 |
| QUALITY BRAND | 54027, Q4122 |
| STANDARD ROTORS AND DRUMS | 54027 |
| THE UNIVERSAL GROUP | 102571 |
| TRUSTAR | 492410, R92410 |
| TopNotch | TN66595GEO |
| UAP | 54027 |
| Universal | 102571 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X51005 |
| WABCO | PS125481 |
| WABCO - Archived | PS125481 |
| WAGNER | BD125481, BD125481E |
| WAGNER BRAKE | BD125481 |
| WINHERE | 441168, YH1168 |
| WORLDPAC | 1407-25446 |
| Wagner Brake | BD125481E |
RAYBESTOS 66595 Fits Vehicles
- Ford Grand Marquis (1996-2002)
- Mercury Grand Marquis (1996-2002)
- Lincoln Town Car (1996-2002)
- Ford Crown Victoria (1996-2002)
