(888) 312-8812 Login SignupRAYBESTOS 66489 Raybestos Specialty - Street Performance Brake Rotor
$7499
Limited availability at this price!
In Stock
Get it by Friday, Jul 10
RAYBESTOS 66489 Part Description
Manufacturer
Product Description
Raybestos Specialty - Street Performance Brake Rotor
Application Summary
2000-1995 Ford Contour Front, 2002-1999 Mercury Cougar Front, 2000-1995 Mercury Mystique Front, 2000-1995 Ford Mystique Front
Features & Benefits
- Application Specific Enhanced Iron
- Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Cooling Vanes
- The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
- Application Specific Coating
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
- Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
- Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
- Turned Finish
- Turned finish minimizes noise and improves responsiveness for smoother stops.
- S-Groove Slot
- Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
- Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.
RAYBESTOS 66489 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.5 IN |
| Center Hole Diameter | 63.5 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 0.874 IN |
| Discard Thickness | 22.2 MM |
| Harmonize Code | 8708.30.5030 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 4.25 IN |
| Mounting Bolt Hole Circle Diameter | 107.95 MM |
| Mounting Bolt Hole Diameter | 0.54 IN |
| Mounting Bolt Hole Diameter | 13.7 MM |
| Mounting Bolt Hole Quantity | 4 |
| Nominal Thickness | 0.945 IN |
| Nominal Thickness | 24 MM |
| Outside Diameter | 10.23 IN |
| Outside Diameter | 259.85 MM |
| Overall Height | 1.85 IN |
| Overall Height | 47 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 4 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00030999793881 |
RAYBESTOS 66489 Cross References
| Brand | Part Number |
|---|---|
| 25175542, 30999793881 | |
| ADVANCE AUTO PARTS | 145044, YH145044, YH145044C, YH145044P |
| AMERICAN REMANUFACTURED | 789-34048, 89-34048 |
| AUTOPART INTERNATIONAL | 25508 |
| AUTOSPECIALTY | AR8148, AR8148E |
| AUTOXTRA | 125428, 8066489, AX54012 |
| AUTOZONE | 54012, 54012B, 54012DG, 54012DL, DL54012 |
| BENDIX | 145044 |
| BOSCH | 20010325, RBR54012 |
| BRAKE HEADQUARTERS | BR54507 |
| BRAKE PRO | 4614012 |
| BRAKEBEST | 20010325, 66489, 66489FZN, 66489R, 66489RGS, 81-125428, BD125428 |
| BREMBO | 09.5707.10, 27002 |
| Brembo | 09.5707.14, 09.5707.75 |
| Bridgestone | 7000956 |
| CALIFORNIA DRUM & ROTOR | 125428 |
| CENTRIC | 120.61048, 121.61048, 125.61048, 126.61048CSL, 126.61048CSR, 126.61048SL, 126.61048SR, 127.61048L, 127.61048R, 128.61048CL, 128.61048CR, 128.61048L, 128.61048R, 320.61048F |
| CONTINENTAL-CONTITECH | CW24120 |
| Casting Numbers | 210649-C, 325195, 540121 |
| Centric Parts | 120.61048, 121.61048, 125.61048, 126.61048CSL, 126.61048CSR, 126.61048SL, 126.61048SR, 127.61048L, 127.61048R, 128.61048CL, 128.61048CR, 128.61048L, 128.61048R, 320.61048F |
| DELPHI | RB135 |
| DURA CORP | BR54012 |
| DuraGo | BR54012 |
| EIS BRAKES | D17725 |
| EUROROTOR | FO135 |
| FORD | 93BZ1125EA, F5RZ1125A, F5RZ1125B, F8RZ1125DA |
| GREN | 646102 |
| GUARDIAN | 52-125428 |
| MIDAS | BR1924 |
| MIGHTY DISTRIBUTING SYSTEM | 54012 |
| MONROE BRAKES | BD125428 |
| MOTORCRAFT | BRR58 |
| NAPA BRAKES | SDK6035 |
| NEOTEK | 107110GF |
| NEWTEK AUTOMOTIVE | 54012 |
| Newtek Automotive USA | 54012 |
| PARTS MASTER | P125428 |
| PROMAX | 14-54012 |
| PRONTO | BR54012 |
| QUALIS | 54012 |
| QUALITEE INTERNATIONAL | 64-92-730 |
| QUALITY BRAND | 54012, Q4013 |
| QUINTON HAZELL | BDC3909 |
| STANDARD ROTORS AND DRUMS | 54012 |
| THE UNIVERSAL GROUP | 102625 |
| TRUSTAR | 492730, R92730 |
| TopNotch | TN66489GEO |
| UAP | 54012 |
| Ultra Brake | FO-135 |
| Universal | 102625 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X50837 |
| WABCO | PS54012 |
| WABCO - Archived | PS54012 |
| WAGNER | BD125428E, BD125428 |
| WAGNER BRAKE | BD125428 |
| WINHERE | 442309, YH2309 |
| Wagner Brake | BD125428E |
RAYBESTOS 66489 Fits Vehicles
- Ford Mystique (1995-2000)
- Mercury Mystique (1995-2000)
- Mercury Cougar (1999-2002)
- Ford Contour (1995-2000)
