(888) 312-8812 Login SignupRAYBESTOS 980417 Raybestos Specialty - Street Performance Brake Rotor
$7099
Limited availability at this price!
1 Day Lead Time
Get it by Thursday, Jul 30
RAYBESTOS 980417 Part Description
Manufacturer
Product Description
Raybestos Specialty - Street Performance Brake Rotor
Application Summary
2010-2006 Hyundai Azera Rear, 2009-2007 Kia Amanti Rear
Features & Benefits
- Application Specific Enhanced Iron
- Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Cooling Vanes
- The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
- Application Specific Coating
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
- Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
- Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
- Turned Finish
- Turned finish minimizes noise and improves responsiveness for smoother stops.
- S-Groove Slot
- Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
- Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.
RAYBESTOS 980417 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.992 IN |
| Center Hole Diameter | 76 MM |
| Conventional Or Drum-In-Hat Type Rotor | Drum-In-Hat |
| Discard Thickness | 0.331 IN |
| Discard Thickness | 8.4 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 4.5 IN |
| Mounting Bolt Hole Circle Diameter | 114.3 MM |
| Mounting Bolt Hole Diameter | 4.5 IN |
| Mounting Bolt Hole Diameter | 114.3 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.392 IN |
| Nominal Thickness | 9.95 MM |
| Outside Diameter | 11.183 IN |
| Outside Diameter | 284.05 MM |
| Overall Height | 2.165 IN |
| Overall Height | 55 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Solid |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352464243 |
RAYBESTOS 980417 Cross References
| Brand | Part Number |
|---|---|
| 98390008, 829352464243 | |
| ADVANCE AUTO PARTS | YH200370, YH200370C |
| ATE BRAKE PRODUCTS | 410336 |
| AUTOPARTSOURCE | 482260 |
| AUTOZONE | 44631, 44631DG |
| BENDIX | PRT5852 |
| BOSCH | 28011486 |
| BRAKEBEST | 28011486, 980417, 980417FZN, 980417R, 980417RGS |
| CENTRIC | 120.51022, 120.51022CRY, 121.51022, 126.51022SL, 126.51022SR, 127.51022L, 127.51022R, 320.51022 |
| Casting Numbers | 326294 |
| Centric Parts | 120.51022, 120.51022CRY, 121.51022, 126.51022SL, 126.51022SR, 127.51022L, 127.51022R, 320.51022 |
| DURA CORP | BR31421, BR900398 |
| DuraGo | 60431, 900398, BR60431, BR900398 |
| Hyundai | 584113L000 |
| KIA | 584113L010 |
| NEOTEK | 106946GF |
| NEWTEK AUTOMOTIVE | 31421 |
| Newtek Automotive USA | 31421 |
| Omnicraft | QBRR654 |
| POWERSTOP | JBR1335EVC |
| PROMAX | 14-31421 |
| PRONTO | BR900398 |
| Qualis | 44631 |
| UAP | 31421 |
| WAGNER | BD126460 |
| WAGNER BRAKE | BD126460 |
| WINHERE | 661742 |
| WORLDPAC | 1407-80298, 1427-719842 |
RAYBESTOS 980417 Fits Vehicles
- Kia Amanti (2007-2009)
- Hyundai Azera (2006-2010)
