9948R by RAYBESTOS - Raybestos R-Line Brake Rotor

Raybestos 9948R - Raybestos R-Line Brake Rotor

Part Number
9948R
Manufacturer
RAYBESTOS
Description

Raybestos R-Line Brake Rotor

details

NO STOCK AVAILABLE

We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.

Sometimes we may have similar parts for sale, click the button below to see if anything matches.

Search Alternatives

RAYBESTOS part description

Product Description

Raybestos R-Line Brake Rotor

Application Summary

1989-1983 Mitsubishi Starion Front, 1987 Chrysler Conquest Front, 1986-1984 Dodge Conquest Front, 1986-1984 Plymouth Conquest Front

Product Attributes

Center Hole Diameter 3.152 IN
Center Hole Diameter 80.05 MM
Conventional Or Drum-In-Hat Type Rotor Conventional
Discard Thickness 0.882 IN
Discard Thickness 22.4 MM
Harmonize Code 8708.30.5030
Mounting Bolt Hole Circle Diameter 3.937 IN
Mounting Bolt Hole Circle Diameter 100 MM
Mounting Bolt Hole Diameter 0.416 IN
Mounting Bolt Hole Diameter 10.55 MM
Mounting Bolt Hole Quantity 4
Nominal Thickness 0.945 IN
Nominal Thickness 24 MM
Outside Diameter 10.08 IN
Outside Diameter 256.05 MM
Overall Height 1.38 IN
Overall Height 35.05 MM
Salability Restrictions No
Solid Or Vented Type Rotor Vented
Stud/Lug Hole Quantity 4
UNSPSC Code 25171715

Additional Information

Country of Origin (Primary) US
UPC 00829352373484

Part Interchanges

RAYBESTOS 9948R Cross Reference

We have 40 alternatives for the 9948R by RAYBESTOS:

Fits Vehicles

  • Mitsubishi Starion (1983-1989)
  • Plymouth Conquest (1984-1986)
  • Dodge Conquest (1984-1986)
  • Chrysler Conquest (1987)
