(888) 312-8812 Login SignupRAYBESTOS 5802R Raybestos R-Line Brake Rotor
$84.71
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
RAYBESTOS 5802R Part Description
Manufacturer
Product Description
Raybestos R-Line Brake Rotor
Application Summary
1978-1969 Cadillac Eldorado Front, 1978-1976 Cadillac Eldorado Rear, 1978-1969 Oldsmobile Toronado Front, 1970-1969 Buick Riviera Front
Features & Benefits
- OE Fit, Form, and Function
- Developed from OE samples and made with G3000-qualified material, ensuring OE fit, form and function for dependable braking.
- SAE Standard
- R-Line Rotors meet the SAE standard for tensile strength, providing structural integrity and a maximum service life.
- Low Initial Lateral Runout and Thickness Variation
- R-Line Rotors have a small parameter lateral runout and a thickness variation ensuring less pedal pulsation, less brake noise, and an extended pad life.
- Mill Balanced Edges
- R-Line Rotors are mill balanced and 100 percent validated. This helps minimize the thickness variation on the rotor and leads to minimized vibration and smoother stopping.
RAYBESTOS 5802R Specifications
Product Attributes
| Center Hole Diameter | 3.083 IN |
| Center Hole Diameter | 78.3 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 1.17 IN |
| Discard Thickness | 29.7 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 5 IN |
| Mounting Bolt Hole Circle Diameter | 127 MM |
| Mounting Bolt Hole Diameter | 0.54 IN |
| Mounting Bolt Hole Diameter | 13.7 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.205 IN |
| Nominal Thickness | 30.6 MM |
| Outside Diameter | 11.005 IN |
| Outside Diameter | 279.55 MM |
| Overall Height | 2.285 IN |
| Overall Height | 58.05 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352364710 |
RAYBESTOS 5802R Cross References
| Brand | Part Number |
|---|---|
| ACCURATE | 22409 |
| ACDELCO | 177-522 |
| ADVANCE AUTO PARTS | YH141007 |
| AMERICAN REMANUFACTURED | 789-36030, 89-36030 |
| AUTOSPECIALTY | AR8230, AR8230E |
| AUTOXTRA | 60407, AX5512 |
| AUTOZONE | 5512 |
| BENDIX | 141007 |
| BRAKE HEADQUARTERS | BR55120 |
| BRAKE PRO | 4615802 |
| BRAKEBEST | 5802, 5802R, 5802RGS, BD60407 |
| CALIFORNIA DRUM & ROTOR | 60242, 60407 |
| CENTRIC | 120.62030, 121.62030, 126.62030SL, 126.62030SR, 127.62030L, 127.62030R |
| CENTURY | 5802 |
| CERTIFIED DIVISION | HR37 |
| Casting Numbers | 210116-C, 325635, 55121, 635802 |
| Centric Parts | 120.62030, 121.62030, 126.62030SL, 126.62030SR, 127.62030L, 127.62030R |
| DURA CORP | BR5512 |
| DuraGo | BR5512 |
| EIS BRAKES | D5402, D5802 |
| EUROROTOR | 5512 |
| GM | 1490626, 5473400 |
| GREN | 685102 |
| General Motors | 1490626, 5473400 |
| HOLLANDER | 1015 |
| KELSEY HAYES | 14518, 83616 |
| MAGMA PRODUCTS | PMR223005 |
| MCI | 5030 |
| MIDAS | BR1028 |
| MIGHTY DISTRIBUTING SYSTEM | 5512 |
| MOPAR | 3-1310 |
| NEWTEK AUTOMOTIVE | 5512 |
| Newtek Automotive USA | 5512 |
| QUALIS | 5512 |
| QUALITY BRAND | 5512 |
| ROADMATES | 526054 |
| ROCKHILL | 5512 |
| STANDARD ROTORS AND DRUMS | 5512 |
| THE UNIVERSAL GROUP | 101120 |
| UAP | 5512 |
| Universal | 101120 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X50061 |
| WAGNER | BD60407 |
| WAGNER BRAKE | BD60407 |
| WINHERE | YH2388 |
RAYBESTOS 5802R Fits Vehicles
- Buick Riviera (1969-1970)
- Oldsmobile Toronado (1969-1978)
- Cadillac Eldorado (1969-1978)
