(888) 312-8812 Login SignupRAYBESTOS 980131R Raybestos R-Line Brake Rotor
MSRP: $61.66
$4299
Save $18.67
Limited availability at this price!
In Stock
Get as soon as Thursday, Oct 15
RAYBESTOS 980131R Part Description
Manufacturer
Product Description
Raybestos R-Line Brake Rotor
Application Summary
2005-2002 Volkswagen Jetta Rear, 2003-2002 Volkswagen Golf Rear, 2006-2000 Audi TT Quattro Rear, 2013-2011 Volkswagen Clasico Rear
Features & Benefits
- OE Fit, Form, and Function
- Developed from OE samples and made with G3000-qualified material, ensuring OE fit, form and function for dependable braking.
- SAE Standard
- R-Line Rotors meet the SAE standard for tensile strength, providing structural integrity and a maximum service life.
- Low Initial Lateral Runout and Thickness Variation
- R-Line Rotors have a small parameter lateral runout and a thickness variation ensuring less pedal pulsation, less brake noise, and an extended pad life.
- Mill Balanced Edges
- R-Line Rotors are mill balanced and 100 percent validated. This helps minimize the thickness variation on the rotor and leads to minimized vibration and smoother stopping.
RAYBESTOS 980131R Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.559 IN |
| Center Hole Diameter | 65 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 0.787 IN |
| Discard Thickness | 20 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 3.937 IN |
| Mounting Bolt Hole Circle Diameter | 100 MM |
| Mounting Bolt Hole Diameter | 3.937 IN |
| Mounting Bolt Hole Diameter | 100 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.862 IN |
| Nominal Thickness | 21.9 MM |
| Outside Diameter | 10.079 IN |
| Outside Diameter | 256 MM |
| Overall Height | 1.433 IN |
| Overall Height | 36.4 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352467503 |
RAYBESTOS 980131R Cross References
| Brand | Part Number |
|---|---|
| ASH12323, 829352467503 | |
| ADVANCE AUTO PARTS | YH145418, YH145418C |
| AUTOXTRA | AX34222 |
| AUTOZONE | 34222, 34222DG |
| BENDIX | 145418 |
| BOSCH | 14010054 |
| BRAKEBEST | 14010054, 980131, 980131FZN, 980131R, 980131RGS |
| BREMBO | 09.A652.11, 25707 |
| Brembo | 09.A652.1S, 09.A652.1X |
| CENTRIC | 120.33069, 121.33069, 125.33069, 125.33069CRY, 126.33069CSL, 126.33069CSR, 126.33069SL, 126.33069SR, 127.33069CL, 127.33069CR, 127.33069L, 127.33069R, 128.33069CL, 128.33069CR, 128.33069L, 128.33069R, 320.33069C |
| Casting Numbers | 325989 |
| Centric Parts | 120.33069, 121.33069, 125.33069, 125.33069CRY, 126.33069CSL, 126.33069CSR, 126.33069SL, 126.33069SR, 127.33069CL, 127.33069CR, 127.33069L, 127.33069R, 128.33069CL, 128.33069CR, 128.33069L, 128.33069R, 320.33069C |
| DURA CORP | BR34222 |
| DuraGo | BR34222 |
| MAGMA PRODUCTS | PMR583050 |
| MIGHTY DISTRIBUTING SYSTEM | 34222 |
| NAPA BRAKES | SDK6259 |
| NEWTEK AUTOMOTIVE | 34222 |
| Newtek Automotive USA | 34222 |
| PAGID | 355106752 |
| PAGID Racing | 355106752 |
| PILENGA | V872 |
| POWERSTOP | EBR647EVC |
| PROMAX | 14-34222 |
| QUALIS | 34222 |
| QUINTON HAZELL | BDC4764 |
| TRW | 4065 |
| UAP | 34222 |
| Ultra Brake | AU-269 |
| VAICO | V1080083 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X51623 |
| VOLKSWAGEN | 8N0615601B |
| WABCO | PS126462 |
| WABCO - Archived | PS126462 |
| WAGNER | BD126462E, BD126462 |
| WAGNER BRAKE | BD126462, BD126462E |
| WINHERE | 662915 |
| WORLDPAC | 1407-78062 |
RAYBESTOS 980131R Fits Vehicles
- Audi TT Quattro (2000-2006)
- Seat Leon (2001-2005)
- Volkswagen Clasico (2011-2013)
- Volkswagen Golf (2002-2006)
- Volkswagen Jetta (2002-2005)
- Volkswagen R32 (2004)
