(888) 312-8812 Login SignupBENDIX 802981 Brake Chamber (Disc)
Tap to view 5 more
SHIPS TODAY
MSRP: $248.73
$14749
Save $101.24
Limited availability at this price!
In Stock
Get as soon as Friday, Oct 23
BENDIX 802981 Part Description
BENDIX 802981 Specifications
Product Attributes
| Cautionary Note(s) | All vent holes must be open |
| Chamber Type / Size | T20 |
| Clamp Angle | 120Adeg |
| Market Indicator | Aftermarket New |
| Maximum Operating Temperature | 176 AdegF (80 AdegC) |
| Minimum Operating Temperature | -40 AdegF (-40 AdegC) |
| Mounting Stud Length | 1.70 IN (43.2 MM) |
| Port Angle | 120Adeg |
| Push Rod Length [MM] | 15 mm |
| Push Rod Thread / Style | Spherical End |
| Service Chamber Joint Type | Single Clamp Band |
| Service Chamber Vent Holes | All Open |
| Service Port (11) - Center | Not applicable to this part |
| Service Port (11) - Side | 3/8-18 NPTF |
| Stroke | 2.50 IN (63.5 MM) |
| Stud Spacing | 4.75 IN (120.7 MM) |
| Stud Thread Size | M16 x 1.5-6g |
Additional Information
| Country of Origin (Primary) | CZ |
| VMRS Code | 013013060 |
BENDIX 802981 Cross References
| Brand | Part Number |
|---|---|
| BW802981 | |
| N/A | K052486 |
