CENTRIC 120.44175 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
- Painted hat and outer edge for corrosion resistance
- Symmetric vane; split-core castings for uniform heat distribution. Anti-corrosive paint protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life.
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 120.44175 Specifications
Product Attributes
| Vane Style [cntrc] | Straight |
| Misc Holes [cntrc] | 8 |
| Hat Id [cntrc] In | 8.248 |
| Max Pb Drum Dia [cntrc] In | 8.307 |
| Weight [cntrc] Lbs | 14.550 |
| Product Grade [cntrc] | Premium |
| Disc Mounting [cntrc] | Floating / DIH |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Hat Id [cntrc] Mm | 209.500 |
| Max Pb Drum Dia [cntrc] Mm | 211.000 |
| Weight [cntrc] Kgs | 6.600 |
| Discard Thickness | 16.000 MM |
| Discard Thickness | 0.630 IN |
| Nominal Thickness | 18.000 MM |
| Nominal Thickness | 0.709 IN |
| Hat Finish | Painted |
| Overall Height | 2.681 IN |
| Overall Height | 68.100 MM |
| Outside Diameter | 312.100 MM |
| Outside Diameter | 12.287 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Nominal Drum Diameter | 209.700 MM |
| Nominal Drum Diameter | 8.256 IN |
| Bearings Included | No |
| Center Hole Diameter | 108.000 MM |
| Center Hole Diameter | 4.252 IN |
| Mounting Bolt Hole Circle Diameter | 139.700 MM |
| Mounting Bolt Hole Circle Diameter | 5.500 IN |
| Stud/Lug Hole Quantity | 6 |
| Stud/Lug Hole Diameter | 0.567 IN |
| Stud/Lug Hole Diameter | 14.400 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00805890631484 |
CENTRIC 120.44175 Cross References
| Brand | Part Number |
|---|---|
| ADVICS | A6R045U |
| N/A | E125-49-180, BR90091202, YH289740, 44715, 31550G, 71918, 4243160311, 850180, DDF1743, 90076143, E12549180 |
| NEOTEK | 1063062GF |
| Neotek Premium Drums and Rotors | 1063062GF |
| PRONTO | BR90091202 |
| RAYBESTOS | 980780, 980780FZN, 980780R, 980780R2 |
| Raybestos Brakes | 980780, 980780FZN, 980780R |
| WAGNER | BD180391E, BD180391 |
CENTRIC 120.44175 Fits Vehicles
- Toyota 4Runner (2010-2023)
- Lexus GX460 (2010-2023)
- Toyota FJ Cruiser (2010-2014)
