(888) 312-8812 Login SignupCENTRIC 131.39006 C-Tek Standard Brake Master Cylinder
Tap to view 6 more
$133.61
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 131.39006 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Master Cylinder
Features & Benefits
- Reservoirs and caps included. Pressure tested for worry free performance. Wide application coverage.
CENTRIC 131.39006 Specifications
Product Attributes
| Publication Bore [cntrc] | 23mm - 16mm |
| Push Rod: Length / Depth [cntrc] In | 0.691 |
| Boss, Nipple Or Port: Front, End [cntrc] | M10-1.00 bbl |
| Boss, Nipple Or Port: Bottom [cntrc] | M10-1.00 bbl |
| Boss, Nipple Or Port: Rear: #a [cntrc] | M10-1.00 bbl |
| Weight [cntrc] Lbs | 1.1 |
| Weight [cntrc] Kgs | 0.5 |
| Master Cylinder Bore Diameter Secondary [cntrc] Mm | 16.000 |
| Master Cylinder Bore Diameter Secondary [cntrc] In | 0.630 |
| Primary Outlet Flare Type [cntrc] | Bubble |
| Secondary Outlet Flare Type [cntrc] | Bubble |
| Product Grade [cntrc] | Standard |
| Reservoir Material | Plastic |
| Mounting Hardware Included | No |
| Mounting Hole Quantity | 2 |
| Brake Booster Included | No |
| Master Cylinder Cap Included | Yes |
| Master Cylinder Material | Aluminum |
| Push Rod Included | No |
| Reservoir Included | Yes |
| Reservoir Type | Single |
| Primary Outlet Thread Diameter | 10.000 MM |
| Secondary Outlet Thread Diameter | 10.000 MM |
| Bleeder Hoses Included | No |
| Port Quantity | 3 |
| Mounting Bracket Included | No |
| Secondary Outlet Thread Pitch | 1.00 MM |
| Primary Outlet Thread Pitch | 1.00 MM |
| Bore Type | Stepped |
| Secondary Outlet Thread Size | M10-1.00 |
| Primary Outlet Thread Size | M10-1.00 |
| Primary Outlet Flare Type | Bubble |
| Secondary Outlet Flare Type | Bubble |
| Primary Bore Diameter | 23.000 MM |
| Primary Bore Diameter | 0.906 IN |
| Secondary Bore Diameter | 16.000 MM |
| Secondary Bore Diameter | 0.630 IN |
| Reservoir Style | Removable |
Additional Information
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8413919050 |
| UPC | 00805890095835 |
CENTRIC 131.39006 Cross References
| Brand | Part Number |
|---|---|
| MC39641, MC390014, F110998, F115618 | |
| N/A | F110998, F115618, 010022, 010023, 6621060, M900565, M900760, 6819671, 68196716, 12960033, 1359543, 13595434, 1359693, 13596937, 1273242, 12732426, 1273243, 12732434, 12217147, 13298807, 13308325, 65-M390014, CM1826, MC390014, MC39641, 12099, 12444, 39641, 390014, 230239006, 2302-39006, PMK331, M21006, M21006E, 18030601, 18030795, 18M359, 18M553, E150024, E150604, M39641 |
| RAYBESTOS | MC390014, MC39641 |
CENTRIC 131.39006 Fits Vehicles
- Volvo 745 (1985)
- Volvo 760 (1983-1986)
- Volvo 740 (1985-1991)
