(888) 312-8812 Login SignupRAYBESTOS 66840R Raybestos R-Line Brake Rotor
$6999
Limited availability at this price!
In Stock
Get as soon as Tuesday, Sep 22
RAYBESTOS 66840R Part Description
Manufacturer
Product Description
Raybestos R-Line Brake Rotor
Application Summary
2005-2002 Ford Thunderbird Rear, 2006-2000 Lincoln LS Rear, 2005-2000 Jaguar S-Type Rear, 2006-2004 Jaguar XJ8 Rear, 2006-2004 Jaguar Vanden Plas Rear
Features & Benefits
- OE Fit, Form, and Function
- Developed from OE samples and made with G3000-qualified material, ensuring OE fit, form and function for dependable braking.
- SAE Standard
- R-Line Rotors meet the SAE standard for tensile strength, providing structural integrity and a maximum service life.
- Low Initial Lateral Runout and Thickness Variation
- R-Line Rotors have a small parameter lateral runout and a thickness variation ensuring less pedal pulsation, less brake noise, and an extended pad life.
- Mill Balanced Edges
- R-Line Rotors are mill balanced and 100 percent validated. This helps minimize the thickness variation on the rotor and leads to minimized vibration and smoother stopping.
RAYBESTOS 66840R Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.54 IN |
| Center Hole Diameter | 64.5 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 0.728 IN |
| Discard Thickness | 18.5 MM |
| Harmonize Code | 8708.30.5030 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 4.25 IN |
| Mounting Bolt Hole Circle Diameter | 107.95 MM |
| Mounting Bolt Hole Diameter | 0.557 IN |
| Mounting Bolt Hole Diameter | 14.15 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.79 IN |
| Nominal Thickness | 20.05 MM |
| Outside Diameter | 11.335 IN |
| Outside Diameter | 287.9 MM |
| Overall Height | 1.275 IN |
| Overall Height | 32.4 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352366110 |
RAYBESTOS 66840R Cross References
| Brand | Part Number |
|---|---|
| 829352366110 | |
| ADVANCE AUTO PARTS | 145269, YH145269, YH145269C, YH145269P |
| AMERICAN REMANUFACTURED | 89-34062 |
| AUSTIN HEALY | JLM20802 |
| AUTOSPECIALTY | AR8162, AR8162E |
| AUTOXTRA | 125724, AX54089 |
| AUTOZONE | 54089, 54089DG, DL54089 |
| BECK/ARNLEY | 083-2808 |
| BENDIX | 145269 |
| BRAKEBEST | 20010378, 66840, 66840FZN, 66840R, 66840RGS, 81-125724, BD125724 |
| BREMBO | 25526 |
| Brembo | 09.7911.21 |
| CENTRIC | 120.61062, 121.61062, 125.61062, 125.61062CRY, 126.61062CSL, 126.61062CSR, 126.61062SL, 126.61062SR, 127.61062L, 127.61062R, 128.61062CL, 128.61062CR, 128.61062L, 128.61062R, 320.61062, 320.61062H |
| CONTINENTAL-CONTITECH | CW20708 |
| Casting Numbers | 1R832C026AA, 211258-C, 325507 |
| Centric Parts | 120.61062, 121.61062, 125.61062, 125.61062CRY, 126.61062CSL, 126.61062CSR, 126.61062SL, 126.61062SR, 127.61062L, 127.61062R, 128.61062CL, 128.61062CR, 128.61062L, 128.61062R, 320.61062, 320.61062H, 320.61062F |
| DURA CORP | BR54089 |
| DuraGo | BR54089 |
| FORD | 1R8Z2C026AA, XW4Z2C026AA |
| JAGUAR | JLM20802, XR827087 |
| MAGMA PRODUCTS | PMR203063 |
| MIGHTY DISTRIBUTING SYSTEM | 54089 |
| MOTORCRAFT | BRR105 |
| Motorcraft | NBRR114 |
| N/A | JLM20802 |
| NAPA BRAKES | SDK6214 |
| NEWTEK AUTOMOTIVE | 54089 |
| Newtek Automotive USA | 54089 |
| PEP BOYS | 54089G |
| POWERSTOP | AR8162EVC |
| PROMAX | 14-54089 |
| QUALIS | 54089 |
| QUALITY BRAND | 54089 |
| QUINTON HAZELL | BDC5225 |
| STANDARD ROTORS AND DRUMS | 54089 |
| THE UNIVERSAL GROUP | 102928 |
| TRW | 4106 |
| UAP | 54089 |
| Universal | 102928 |
| VAICO | V5480001 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X51305 |
| WABCO | PS125724 |
| WABCO - Archived | PS125724 |
| WAGNER | BD125724 |
| WAGNER BRAKE | BD125724 |
| WINHERE | 662654, YH2654 |
| WORLDPAC | 1407-25696 |
RAYBESTOS 66840R Fits Vehicles
- Jaguar XJR (2003)
- Jaguar Vanden Plas (2004-2006)
- Jaguar XJ8 (2003-2006)
- Lincoln LS (2000-2006)
- Ford Thunderbird (2002-2005)
- Jaguar S-Type (2000-2005)
