(888) 312-8812 Login SignupCENTRIC 130.70005 Centric Premium Brake Master Cylinder
*Representative image - actual part not displayed
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 130.70005 Part Description
Manufacturer
Product Description
Centric Premium Brake Master Cylinder
Features & Benefits
- Match O.E. parts in quality; configuration and fitment. Complete with reservoirs; switches and floats. Original aluminum casting body design where applicable. Manufactured under the highest quality standards by OEM and OES manufacturers
CENTRIC 130.70005 Specifications
Product Attributes
| Publication Bore [cntrc] | 1" |
| Weight [cntrc] Lbs | 7.1 |
| Product Grade [cntrc] | Premium |
| Boss, Nipple Or Port: Rear: #a [cntrc] | 9/16"-18 inv |
| Secondary Outlet Flare Type [cntrc] | Inverted |
| Boss, Nipple Or Port: Front, Left: #a [cntrc] | 1/2"-20 inv |
| Primary Outlet Flare Type [cntrc] | Inverted |
| Push Rod: Length / Depth [cntrc] In | 1.43 |
| Weight [cntrc] Kgs | 3.23 |
| Reservoir Material | Cast Iron |
| Mounting Hardware Included | No |
| Mounting Hole Quantity | 2 |
| Master Cylinder Bore Diameter | 25.400 MM |
| Master Cylinder Bore Diameter | 1.000 IN |
| Brake Booster Included | No |
| Master Cylinder Cap Included | Yes |
| Master Cylinder Material | Cast Iron |
| Push Rod Included | No |
| Reservoir Included | Yes |
| Reservoir Type | Single |
| Primary Outlet Thread Diameter | 0.5625 IN |
| Secondary Outlet Thread Diameter | 0.5000 MM |
| Bleeder Hoses Included | No |
| Port Quantity | 2 |
| Mounting Bracket Included | No |
| 9275 | 20 IN |
| 9276 | 18 IN |
| Bore Type | Straight |
| Bore Size | 25.400 MM |
| Bore Size | 1.000 IN |
| Primary Outlet Thread Size | 9/16"-18 |
| Primary Outlet Flare Type | Inverted |
| Secondary Outlet Flare Type | Inverted |
| Primary Bore Diameter | 25.400 MM |
| Primary Bore Diameter | 1.000 IN |
| Reservoir Style | Integral |
Additional Information
| Harmonized Tariff Code (HTS) | 8413919050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890010326 |
CENTRIC 130.70005 Part Interchanges
| Brand | Part Number |
|---|---|
| N/A | F73353, E135-75-010, M900152, 356038C91, CM1591, 65-M36362, MC36362, 36362, 2302-70005, 230270005, M93005, 174287, E73354, E13575010 |
CENTRIC 130.70005 Fits Vehicles
- International 1100B (1967)
- International 1000B (1967)
- International M800 Post Office (1969-1972)
- International M800 Navy (1969)
- International M800 (1965-1971)
- International M1100 (1965-1972)
- International M Series Van (1964)
- International 1100C (1968)
- International 1000C (1968)
