(888) 312-8812 Login SignupCENTRIC 130.50021 Centric Premium Brake Master Cylinder
*Representative image - actual part not displayed
$173.47
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 130.50021 Part Description
Manufacturer
Product Description
Centric Premium Brake Master Cylinder
Application Summary
Kia Sorento 2006-2004
Features & Benefits
- Match O.E. parts in quality; configuration and fitment. Complete with reservoirs; switches and floats. Original aluminum casting body design where applicable. Manufactured under the highest quality standards by OEM and OES manufacturers
- Compliant to SAE J1154 requirements for optimal performance and durability
- SAE J1154 Compliant
- OE Style Castings
- OE style castings and complete with reservoirs, switches, and floats (where applicable)
- 100% Pressure Tested
- To ensure optimal performance
Centric; CentricParts; Centric Parts; Centric Master Cylinder; Centric Parts Master Cylinder
CENTRIC 130.50021 Specifications
Product Attributes
| Reservoir Material | Plastic |
| Mounting Hardware Included | No |
| Mounting Hole Quantity | 2 |
| Master Cylinder Bore Diameter | 1.063 IN |
| Brake Booster Included | No |
| Master Cylinder Cap Included | Yes |
| Master Cylinder Material | Al |
| Push Rod Included | No |
| Reservoir Included | Yes |
| Reservoir Type | Single |
| Primary Outlet Thread Diameter | 10.000 MM |
| Secondary Outlet Thread Diameter | 16.000 MM |
| Bleeder Hoses Included | No |
| Port Quantity | 2 |
| Mounting Bracket Included | No |
| Secondary Outlet Thread Pitch | 1.50 MM |
| Primary Outlet Thread Pitch | 1.00 MM |
| Bore Type | Straight |
| Bore Size | 26.988 MM |
| Secondary Outlet Thread Size | M10 - 1.0 |
| Primary Outlet Thread Size | M10 - 1.0 |
| Primary Outlet Flare Type | Bubble |
| Secondary Outlet Flare Type | Open |
| Primary Bore Diameter | 26.988 MM |
| Reservoir Style | Removable |
| Boss, Nipple Or Port: Front, Left: #a [cntrc] | M10-1.00 bbl |
| Boss, Nipple Or Port: Front, Right: #a [cntrc] | M16-1.50 |
| Boss, Nipple Or Port: Rear, Bottom [cntrc] | M16-1.50 |
| Boss, Nipple Or Port: Rear: #a [cntrc] | M10-1.00 bbl |
| Primary Outlet Flare Type [cntrc] | Bubble |
| Publication Bore [cntrc] | 1 1/16" |
| Push Rod: Length / Depth [cntrc] In | 1.67 |
| Secondary Outlet Flare Type [cntrc] | Open |
| Weight [cntrc] Kgs | 0.91 |
| Weight [cntrc] Lbs | 2 |
| Product Grade [cntrc] | Premium |
| Bore Size (mm) | 27.03 |
| Primary Port Thread A | M10x1 |
| Secondary Port Thread A | M10x1 |
| Bore Size (in) | 1.06 |
| Master Cylinder Bore Diameter | 26.988 MM |
| Mounting Hole Diameter | 0.343 IN |
| Mounting Hole Diameter | 8.700 MM |
| Primary Bore Diameter | 1.063 IN |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8413919096 |
| NAFTA Preference Criterion Code | B |
| Canadian Harmonizing Tariff Code | 8413910090 |
| OEM's Part Number | 591203E200 |
| Original Equipment Manufacturer | CNXN |
| UPC | 00805890500803 |
CENTRIC 130.50021 Cross References
CENTRIC 130.50021 Fits Vehicles
- Kia Sorento (2004-2006)
