(888) 312-8812 Login SignupCENTRIC 130.45306 Centric Premium Brake Master Cylinder
$17899
Limited availability at this price!
5 Day Lead Time
Get it by Wednesday, Dec 24
CENTRIC 130.45306 Part Description
Manufacturer
Product Description
Centric Premium Brake Master Cylinder
Features & Benefits
- Match O.E. parts in quality; configuration and fitment. Complete with reservoirs; switches and floats. Original aluminum casting body design where applicable. Manufactured under the highest quality standards by OEM and OES manufacturers
CENTRIC 130.45306 Specifications
Product Attributes
| Push Rod: Length / Depth [cntrc] In | 1.28 |
| Boss, Nipple Or Port: Rear: #a [cntrc] | M10-1.00 inv |
| Boss, Nipple Or Port: Center, Bottom [cntrc] | screw |
| Weight [cntrc] Lbs | 2.75 |
| Primary Outlet Flare Type [cntrc] | Inverted |
| Product Grade [cntrc] | Premium |
| Publication Bore [cntrc] | 15/16" |
| Boss, Nipple Or Port: Front, Top [cntrc] | M10-1.00 inv |
| Boss, Nipple Or Port: Rear, Right: #a [cntrc] | M10-1.00 inv |
| Boss, Nipple Or Port: Rear, Bottom [cntrc] | M10-1.00 bbl |
| Weight [cntrc] Kgs | 1.25 |
| Secondary Outlet Flare Type [cntrc] | Inverted |
| Reservoir Material | Plastic |
| Mounting Hardware Included | No |
| Mounting Hole Quantity | 2 |
| Master Cylinder Bore Diameter | 23.813 MM |
| Master Cylinder Bore Diameter | 0.938 IN |
| Brake Booster Included | No |
| Master Cylinder Cap Included | Yes |
| Master Cylinder Material | Aluminum |
| Push Rod Included | No |
| Reservoir Included | Yes |
| Reservoir Type | Single |
| Primary Outlet Thread Diameter | 10.000 MM |
| Secondary Outlet Thread Diameter | 10.000 MM |
| Bleeder Hoses Included | No |
| Port Quantity | 3 |
| Mounting Bracket Included | No |
| Secondary Outlet Thread Pitch | 1.00 MM |
| Primary Outlet Thread Pitch | 1.00 MM |
| Bore Type | Straight |
| Bore Size | 23.813 MM |
| Bore Size | 0.938 IN |
| Secondary Outlet Thread Size | M10-1.00 |
| Primary Outlet Thread Size | M10-1.00 |
| Primary Outlet Flare Type | Inverted |
| Secondary Outlet Flare Type | Inverted |
| Primary Bore Diameter | 23.813 MM |
| Primary Bore Diameter | 0.938 IN |
| Reservoir Style | Removable |
Additional Information
| Harmonized Tariff Code (HTS) | 8413919050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890220411 |
CENTRIC 130.45306 Part Interchanges
| Brand | Part Number |
|---|---|
| N/A | F142452, MC142452, E135-50-311, 230245306, 2302-45306, 35580054, E13550311, LD4743400, LD4743400A, MC390943 |
