CENTRIC 130.44916 Part Description
Manufacturer
Product Description
Centric Premium Brake Master Cylinder
Features & Benefits
- Match O.E. parts in quality; configuration and fitment. Complete with reservoirs; switches and floats. Original aluminum casting body design where applicable. Manufactured under the highest quality standards by OEM and OES manufacturers
CENTRIC 130.44916 Specifications
Product Attributes
| Publication Bore [cntrc] | 13/16" |
| Boss, Nipple Or Port: Center, Bottom [cntrc] | M6-1.00 screw |
| Secondary Outlet Flare Type [cntrc] | Inverted |
| Boss, Nipple Or Port: Rear, Right: #a [cntrc] | M10-1.00 inv |
| Primary Outlet Flare Type [cntrc] | Inverted |
| Boss, Nipple Or Port: Front, Top [cntrc] | M10-1.00 inv |
| Weight [cntrc] Kgs | 1.14 |
| Push Rod: Length / Depth [cntrc] In | 2.16 |
| Weight [cntrc] Lbs | 2.5 |
| Product Grade [cntrc] | Premium |
| Reservoir Material | Plastic |
| Mounting Hardware Included | No |
| Gasket Or Seal Included | Yes |
| Mounting Hole Quantity | 2 |
| Master Cylinder Bore Diameter | 20.638 MM |
| Master Cylinder Bore Diameter | 0.813 IN |
| Brake Booster Included | No |
| Master Cylinder Cap Included | Yes |
| Master Cylinder Material | Aluminum |
| Push Rod Included | No |
| Reservoir Included | Yes |
| Reservoir Type | Single |
| Primary Outlet Thread Diameter | 10.000 MM |
| Secondary Outlet Thread Diameter | 10.000 MM |
| Bleeder Hoses Included | No |
| Port Quantity | 2 |
| Mounting Bracket Included | No |
| Secondary Outlet Thread Pitch | 1.00 MM |
| Primary Outlet Thread Pitch | 1.00 MM |
| Bore Type | Straight |
| Bore Size | 20.638 MM |
| Bore Size | 0.813 IN |
| Secondary Outlet Thread Size | M10-1.00 |
| Primary Outlet Thread Size | M10-1.00 |
| Primary Outlet Flare Type | Inverted |
| Secondary Outlet Flare Type | Inverted |
| Primary Bore Diameter | 20.638 MM |
| Primary Bore Diameter | 0.813 IN |
| Reservoir Style | Removable |
Additional Information
| Harmonized Tariff Code (HTS) | 8413919050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890193869 |
CENTRIC 130.44916 Part Interchanges
| Brand | Part Number |
|---|---|
| N/A | MC141663, E135-49-921, 230244916, 2302-44916, 35576180, E13549921, M630415, 4720142240, 4720142241, MC390832, 13853 |
CENTRIC 130.44916 Fits Vehicles
- Toyota RAV4 (2003-2005)
