(888) 312-8812 Login SignupCENTRIC 130.39004 Centric Premium Brake Master Cylinder
*Representative image - actual part not displayed
$84.76
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 130.39004 Part Description
Manufacturer
Product Description
Centric Premium Brake Master Cylinder
Application Summary
Volvo 242 1981-1975, 244 1984-1975, 245 1984-1975
Features & Benefits
- Match O.E. parts in quality; configuration and fitment. Complete with reservoirs; switches and floats. Original aluminum casting body design where applicable. Manufactured under the highest quality standards by OEM and OES manufacturers
Centric; CentricParts; Centric Parts; Centric Master Cylinder; Centric Parts Master Cylinder
CENTRIC 130.39004 Specifications
Product Attributes
| Reservoir Material | Plastic |
| Mounting Hardware Included | No |
| Gasket Or Seal Included | Yes |
| Mounting Hole Quantity | 2 |
| Brake Booster Included | No |
| Master Cylinder Cap Included | No |
| Master Cylinder Material | Cast Iron |
| Push Rod Included | No |
| Reservoir Included | No |
| Primary Outlet Thread Diameter | 10.000 MM |
| Secondary Outlet Thread Diameter | 10.000 MM |
| Bleeder Hoses Included | No |
| Port Quantity | 2 |
| Mounting Bracket Included | No |
| Secondary Outlet Thread Pitch | 1.00 MM |
| Primary Outlet Thread Pitch | 1.00 MM |
| Bore Type | Stepped |
| Secondary Outlet Thread Size | M10-1.00 |
| Primary Outlet Thread Size | M10-1.00 |
| Primary Outlet Flare Type | Bubble |
| Secondary Outlet Flare Type | Bubble |
| Primary Bore Diameter | 22.000 MM |
| Secondary Bore Diameter | 15.000 MM |
| Reservoir Style | Removable |
| Boss, Nipple Or Port: Front, End [cntrc] | M10-1.00 bbl |
| Boss, Nipple Or Port: Rear: #a [cntrc] | M10-1.00 bbl |
| Master Cylinder Bore Diameter Secondary [cntrc] In | 0.591 |
| Master Cylinder Bore Diameter Secondary [cntrc] Mm | 15.000 |
| Primary Outlet Flare Type [cntrc] | Bubble |
| Publication Bore [cntrc] | 22mm - 15mm |
| Push Rod: Length / Depth [cntrc] In | 0.711 |
| Secondary Outlet Flare Type [cntrc] | Bubble |
| Weight [cntrc] Kgs | 1.45 |
| Weight [cntrc] Lbs | 3.2 |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8413919050 |
| NAFTA Preference Criterion Code | B |
| UPC | 00805890001881 |
CENTRIC 130.39004 Cross References
CENTRIC 130.39004 Fits Vehicles
- Volvo 245 (1975-1984)
- Volvo 244 (1975-1984)
- Volvo 242 (1975-1981)
