(888) 312-8812 Login SignupCENTRIC 407.66012 Centric Premium Hub and Bearing Assembly; With Integral ABS
Tap to view 1 more
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 407.66012 Part Description
Manufacturer
Product Description
Centric Premium Hub and Bearing Assembly; With Integral ABS
Features & Benefits
- 100% O.E. Quality Components. Premium seals protect internal components. Exacting Fit and Function. Complete cataloging; featuring the latest applications and covering from 1940 to 2017
- Double Row Ball or Taper Roller Bearings include integral encoder for ABS and TCS where applicable
- Gen 1
- Gen 2
- Double Row Ball or Taper Roller Bearing Assemblies include one mounting flange - includes integral encoder for ABS, TCS where applicable
- Gen 3
- Double Row Ball or Taper Roller Bearing Assemblies include 2 mounting flanges - includes integral ABS sensor where applicable
CENTRIC 407.66012 Specifications
Product Attributes
| Notes [cntrc] | Must Have Sensor Assembly Attached - 4 plastic clips + 1 double clip at the end with conector, 1 metal bracket with 1x6M-1.0 bolt |
| Product Grade [cntrc] | Premium |
| Bolt Circle Diameter [cntrc] In | 5.500 |
| Bolt Circle Diameter [cntrc] Mm | 139.700 |
| Mounting Hole Qty [cntrc] | 4 |
| Thread Pitch To Wheel Mounting [cntrc] Mm | 1.500 |
| Mounting Thread Pitch [cntrc] Mm | 1.750 |
| Mouting Thread Size [cntrc] Mm | 12.000 |
| Off-set [cntrc] In | 67.230 |
| Off-set [cntrc] Mm | 2.647 |
| Wheel Stud Size | 14.000 MM |
| Wheel Pilot Diameter | 99.520 MM |
| Wheel Pilot Diameter | 3.918 IN |
| Brake Pilot Diameter | 99.950 MM |
| Brake Pilot Diameter | 3.935 IN |
| Wheel Stud Quantity | 8 |
| Wheel Studs Included | Yes |
| Flange Diameter | 7.245 IN |
| Flange Diameter | 184.020 MM |
Additional Information
| Harmonized Tariff Code (HTS) | 8482105016 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | DE |
| UPC | 00805890568278 |
CENTRIC 407.66012 Cross References
CENTRIC 407.66012 Fits Vehicles
- Chevrolet Colorado (2004-2005)
- GMC Canyon (2004-2005)
