(888) 312-8812 Login SignupDELPHI TC6794 Control Arm and Ball Joint Assembly
Tap to view 1 more
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
DELPHI TC6794 Part Description
Control Arm w/ Ball Jnt
DELPHI TC6794 Specifications
Product Attributes
| Position(s) | Front Right Upper |
| Pre-Greased | Yes |
| Grease Fitting Included | No |
| Bushings Included | Yes |
| Ball Joint Mounting Type | Press In |
| Ball Joint Stud Type | Threaded |
| Control Arm Construction | Casting/Forged |
| Control Arm Material | Steel |
| Mounting Hardware Included | Yes |
| Mounting Hole Quantity | 2 |
| Adjustable | No |
| Greaseable | No |
| Control Arm Maximum Width | 11.024 IN |
| Control Arm Maximum Width | 280.00 MM |
| Control Arm Color | Black |
| Ball Joint Thread Diameter | 0.551 IN |
| Ball Joint Thread Diameter | 14.00 MM |
| Ball Joint Stud Length | 0.886 IN |
| Ball Joint Stud Length | 22.50 MM |
| Control Arm Maximum Length | 11.417 IN |
| Control Arm Maximum Length | 290.00 MM |
| Bushing Material | Rubber |
| Mounting Hole Diameter | 0.492 IN |
| Mounting Hole Diameter | 12.50 MM |
| Thread Direction | Clockwise (Right) |
| Bushing Color | Black |
| Finish | Painted |
| Dust Boot Included | Yes |
| Ball Joint Included | Yes |
| Grade Type | Premium |
| Boot Material | Chloroprene Rubber (CR) |
| Locking Nut Included | Yes |
| Thread Diameter | 14.00 MM |
| Boot Color | Black |
| Steering Type | Power |
| Bearing Material | Plastic |
| Dust Boot Material | Chloroprene Rubber (CR) |
| Thread Diameter | 0.551 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Country of Origin (Primary) | TR |
| UPC | 00689604381885 |
| VMRS Code | 016001002 |
| UNSPSC | 25172013 |
DELPHI TC6794 Part Interchanges
| Brand | Part Number |
|---|---|
| Mevotech | CMS251236 |
| Chrysler | 68282 328AA, K68282328AA |
| N/A | RK623433, 68224 238AB, 68291036AA, 68291 036AB, 68224 239AB |
DELPHI TC6794 Fits Vehicles
- Jeep Grand Cherokee WK (2022)
- Jeep Grand Cherokee (2016-2021)
- Dodge Durango (2016-2022)
DELPHI TC6794 Manufacturer Information
Delphi® is committed to making a difference. With a global network of more than 2,400 service centers and a presence in over 150 countries, Delphi Technologies delivers OE-specific aftermarket parts and software solutions for a wide range of passenger vehicles, light and medium commercial vehicles, heavy-duty truck and commercial vehicles, as well as agricultural, marine, and industrial equipment. The company’s comprehensive product portfolio includes components for diesel fuel systems, engine management, gasoline fuel systems, vehicle electronics, and maintenance solutions. Delphi Technologies takes pride in its state-of-the-art manufacturing facility as well as OE-level diagnostic and test equipment that produces OE-quality aftermarket components to make vehicles and trucks run cleaner, drive better, and last further.
