Bilstein 24-313988 - 46mm Monotube Shock Absorber
$19949
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
BILSTEIN part description
BRONCO 4WD; BASE 4DR; '21+; R; B8 5
Product Description
B8 5100 (Ride Height Adjustable) - Shock Absorber
Application Summary
Ford Bronco 2022-2021
Features & Benefits
- 46mm monotube design ensures consistent, fade-free performance in all conditions
- Practical alternative to coil spring spacers, with the benefit of Bilstein monotube technology
- Adjustable spring seat offers 0-2.75in of lift, depending on the application
Product Attributes
| Adjustable Damping | Non-Adjustable |
| Body Design | Snap Ring Grooved Body (Coilover) |
| Body Diameter (id) | 46mm |
| Boot Included | No |
| Collapsed Length (in) | 17.11 |
| Collapsed Length (mm) | 434.6 |
| Extended Length (in) | 25.56 |
| Extended Length (mm) | 649.3 |
| Finish | Zinc Plated |
| Internal Design | Monotube |
| Lower Mount Type | Eye 20.2mm |
| RESERVOIR | No |
| Series | B8 5100 (Ride Height Adjustable) |
| Spring Seat Included | No - Reuse OEM |
| Title | Bilstein Shock Absorbers |
| Upper Mount Type | Stem |
| Parttype | Shocks / Struts |
| Prop 65 (Y/N) | Y |
| Segment | Light Truck |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| MSDS Sheet Number | USA SDS_Shock_Air Spring_V2_EN.pdf |
| Refurbished Part | N |
| Remanufactured Part | N |
| Warranty Special | Lifetime |
| Warranty Special UOM | LF |
| UPC | 00651860875507 |
Fits Vehicles
- Ford Bronco (2021-2024)
