TrakMotive VW-8002 - CV Axle Shaft
- Part Number
- VW-8002
- Manufacturer
- TRAKMOTIVE
- Description
-
CV Axle Shaft
details
$3699
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
TRAKMOTIVE part description
Product Description
CV Axle Shaft
Product Attributes
| ABS Ring Tooth Count | 0 |
| ABS Ring Type | N/A |
| Abs Tone Ring Included | No |
| Axle Bolt Hex Size (mm) | N/A |
| Axle Bolt Length (mm) | N/A |
| Axle Bolt Thread Size | N/A |
| Axle Nut Head Type | Hex |
| Axle Nut Height (in) | .56 |
| Axle Nut Height (mm) | 14 |
| Axle Nut Hex Size (in) | 1.67 |
| Axle Nut Hex Size (mm) | 30 |
| Axle Nut Included | Yes |
| Axle Nut Length (in) | 1.33 |
| Axle Nut Length (mm) | 35 |
| Axle Nut Locking Type | Self-Lock |
| Axle Nut Thread Size | M20x1.5 |
| Boot Material | Neoprene |
| Inboard Bolt Head Size (in) | N/A |
| Inboard Bolt Head Size (mm) | N/A |
| Inboard Bolt Head Type | N/A |
| Inboard Bolt Length (in) | N/A |
| Inboard Bolt Length (mm) | N/A |
| Inboard Bolt Thread Size | N/A |
| Inboard Joint Type | Flange |
| Inboard Shaft Connection Style | Flange |
| New Or Remanufactured | New |
| Number of Bolt Holes | 0 |
| Number Of Inboard Joint Bolt Holes | 0 |
| Number Of Inboard Shaft Bolts | 0 |
| Number Of Inboard Splines | 0 |
| Number Of Outboard Joint Bolt Holes | 0 |
| Number Of Outboard Shaft Bolts | 0 |
| Number Of Outboard Splines | 22 |
| Outboard Bolt Head Size (in) | N/A |
| Outboard Bolt Head Size (mm) | N/A |
| Outboard Bolt Head Type | N/A |
| Outboard Bolt Length (in) | N/A |
| Outboard Bolt Length (mm) | N/A |
| Outboard Joint Bolt Thread Size | N/A |
| Outboard Joint Type | Conventional |
| Outboard Shaft Connection Style | Conventional |
| Overall Compressed Length (in) | 30.63 |
| Overall Compressed Length (mm) | 778 |
| Axle Nut Socket Size | 30 |
| Grade Type | Premium |
| Inboard Joint Boot Material | Neoprene |
| Outboard Joint Boot Material | Neoprene |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708508500 |
| UPC | 00844084097026 |
Part Interchanges
- ARC 80-3159
- EMPI 80-6809
- Car Components Technologies (CCT) 6038
- Mevotech CV7062
- Carquest 410444
- Carquest 800444
- USA Industries 703227
- USA Industries AX-3227
- Prestige Autotech 3042
- American Remanufactured 40-18846
- Diversified Shafts Solutions 2235N
- Drive Tech America VW-8806
- Drive Tech America VW-8846
- Fenwick CV1478
- CARDONE Reman 60-7100
- CARDONE Reman 66-7100
- IMC 40754054
- IMC 40754092
- OEM Part Number 1EM407274
- OEM Part Number 1H0407272A
- OEM Part Number 1H0407272AM
- OEM Part Number 1H0407452X
- OEM Part Number 1HM407272
- OEM Part Number 1HM407272C
- OEM Part Number 1HM407274C
- OEM Part Number JZW407450TX
- OEM Part Number MULTIPLE
- Altrom Group 652722
- ODM VW-8-8546
- TrakMotive VW-8002
- ProTech VW10513T
- 410444
- NCV72046
- 75880
- MX-18846
- 349002
- 301620
Fits Vehicles
- Volkswagen Passat (1995-1997)
- Volkswagen Cabrio (1995-2002)
- Volkswagen Golf (1993-1999)
- Volkswagen Jetta (1993-1999)
