Centric 123.67042 - C-Tek Standard Brake Drum
$10699
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
Product Attributes
| Weight [cntrc] Kgs | 12.273 |
| Weight [cntrc] Lbs | 27.000 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 114.300 |
| Bolt Circle Diameter [cntrc] In | 4.500 |
| Hub Hole / Register [cntrc] Mm | 71.882 |
| Hub Hole / Register [cntrc] In | 2.830 |
| Height [cntrc] Mm | 118.110 |
| Height [cntrc] In | 4.650 |
| Friction Surface Width [cntrc] Mm | 77.470 |
| Friction Surface Width [cntrc] In | 3.050 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 282.300 MM |
| Maximum Brake Diameter (Discard) | 11.114 IN |
| Bolt Hole Quantity | 6 |
| Outside Diameter | 329.946 MM |
| Outside Diameter | 12.990 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 16.764 MM |
| Mounting Hole Diameter | 0.660 IN |
| Nominal Drum Diameter | 280.200 MM |
| Nominal Drum Diameter | 11.030 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890241683 |
Part Interchanges
CENTRIC 123.67042 Cross Reference
We have 4 alternatives for the 123.67042 by CENTRIC:
Fits Vehicles
- Dodge Dakota (2003-2004)
