Centric 123.65043 - C-Tek Standard Brake Drum
$9899
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
Product Attributes
| Weight [cntrc] Kgs | 10.045 |
| Weight [cntrc] Lbs | 22.100 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 114.300 |
| Bolt Circle Diameter [cntrc] In | 4.500 |
| Hub Hole / Register [cntrc] Mm | 87.376 |
| Hub Hole / Register [cntrc] In | 3.440 |
| Height [cntrc] Mm | 99.822 |
| Height [cntrc] In | 3.930 |
| Friction Surface Width [cntrc] Mm | 67.564 |
| Friction Surface Width [cntrc] In | 2.660 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 281.600 MM |
| Maximum Brake Diameter (Discard) | 11.080 IN |
| Bolt Hole Quantity | 5 |
| Outside Diameter | 325.120 MM |
| Outside Diameter | 12.800 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 14.500 MM |
| Mounting Hole Diameter | 0.571 IN |
| Nominal Drum Diameter | 280.200 MM |
| Nominal Drum Diameter | 11.030 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890239895 |
Part Interchanges
CENTRIC 123.65043 Cross Reference
We have 2 alternatives for the 123.65043 by CENTRIC:
Fits Vehicles
- Ford Explorer Sport Trac (2001-2002)
